About the product
The TRENDnet 26-Port Industrial Gigabit L2 Managed Rackmount Switch is a hardened IP30 rated gigabit switch with SFP ports capable of an extreme operating temperature range of -40° – 70° C (-40° – 158° F). Perfect for industrial environments and non-climate-controlled installations. Coupled with an IP30 rated metal enclosure with shock and vibration protection, the TI-RG262i is suitable for a wide variety of gigabit and fiber SPF long-distance networking installations, including industrial and manufacturing sites, offsite management facilities, warehousing, parking garages, and more.
With an easy-to-use web-based management interface and L2 management features, administrators can route and optimize traffic, troubleshoot, use SNMP monitoring and other advanced network controls. VLAN grouping, QoS and per-port bandwidth managed switch controls simplify network organization and optimization.
TI-RG262i Specs and Features:
- Device Interface
- 24 x Gigabit ports
- 2 x Gigabit SFP ports
- 1 x Console port (RJ-45)
- Fixed 2-pin power terminal
- LED indicators
- Standards: IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.1ax, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az
- Data Transfer Rate:
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit Ethernet: 2000Mbps (full duplex)
- SFP: 2000Mbps (full duplex)
- Performance:
- Switch fabric: 52Gbps
- Data RAM buffer: 512KB
- MAC address table: 8K entries
- Jumbo frames: 10KB
- Forwarding mode: store and forward
- Forwarding rate: 38.7Mpps (64-byte packet size)
- Management:
- HTTP web-based GUI
- CLI: Telnet / SSHv2
- SNMP v1, v2c, v3
- SNMP trap (up to 5 receivers)
- RMON groups 1/2/3/9
- Device configuration backup & restore, upgrade firmware, reboot, and reset to default
- Multiple administrative or read-only user accounts
- Enable or disable power saving mode per port
- Static MAC entries
- Static unicast entries
- LLDP (Link layer discovery protocol)
- Netlite device map
- ONVIF device discovery
- SNTP
- SMTP alert
- Syslog
- Port statistics/utilization
- Traffic monitor
- Port mirror: one to one, many to one
- Storm control: Broadcast, multicast, destination lookup failure (Min. limit: 1pps)
- Loopback detection
- DHCP relay/option 82
- Modbus/TCP
- ERPS (Ethernet Ring Protection Switching) G8032v2
- MIB:
- MIB II RFC 1213
- Bridge MIB RFC 1493
- RMON (Group 1,2,3,9) RFC 2819 RFC 1757
- Spanning Tree:
- IEEE 802.1d STP (spanning tree protocol)
- IEEE 802.1w RSTP (rapid spanning tree protocol)
- BPDU filter, guard, and root guard
- Link Aggregation:
- Static link aggregation and 802.1ax/802.3ad dynamic LACP (Up to 8 groups)
- Quality of Service (QoS)
- 802.1p Class of service (CoS)
- DSCP (Differentiated Services Code Point)
- Bandwidth control per port
- Queue Scheduling: strict priority (SP), weighted round robin (WRR), weighted fair queuing (WFQ)
- VLAN:
- 802.1Q tagged VLAN
- MAC-based VLAN
- Port isolation
- Up to 256 VLAN groups, ID range 1-4094
- Multicast:
- IGMP snooping v1, v2, v3
- IGMP querier
- IGMP fast/immediate leave
- Up to 256 multicast groups
- Static multicast entries
- Access Control:
- 802.1X authentication (Local user database, RADIUS, guest VLAN assignment)
- DHCP snooping/screening
- Trusted host/IP access list for management access
- Port Security/MAC address learning restriction (Up to 100 entries per port)
- Static/dynamic ARP inspection
- ACL:
- Source/Destination MAC address
- Source/Destination IP address
- Source Interface
- VLAN ID
- EtherType
- TCP/UDP port 1-65535
- Special Features:
- Netlite device discovery and map display in GUI
- Port security: MAC address learning restriction per port
- DHCP relay/option 82 & DHCP server snooping/screening support
- Wide operating temperature range
- Surge and ESD protection
- Power:
- Power terminal input: 48 – 57V DC
- Compatible power supply: TI-S15052
- Max. Consumption: 20W
- Terminal Block
- Power input, 2 pin
- Wire range: 1.5 mm^2 to 2.5 mm^2
- Solid wire (AWG): 12-18
- Stranded wire (AWG): 12-18
- Wire strip length: 10-11mm
- Enclosure:
- IP30 rated metal enclosure
- Fanless passive cooling
- Rack mountable 1U
- Grounding point
- ESD (Ethernet) Protection: 8KV DC (Air) 4KV (Contact)
- Surge (Power) Protection: 1KV DC
- Operating Temperature: -40° – 70° C (-40° – 158° F
- Dimensions: 440 x 284 x 44mm (17.32 x 11.18 x 1.7 in.)
- Weight: 3.46kg (7.62 lbs.)
- Certifications: CE, FCC, Shock (IEC 60068-2-27), Freefall (IEC 60068-2-31), Vibration (IEC 60068-2-6)
- Package Includes
- 1x TI-RG262i
- Quick Installation Guide
- Console cable (RJ-45 to RS-232)
- Rackmount kit
- Lifetime Manufacturer's Warranty
Technical Specifications
The TRENDnet 26-Port Industrial Gigabit L2 Managed Rackmount Switch is a hardened IP30 rated gigabit switch with SFP ports capable of an extreme operating temperature range of -40° – 70° C (-40° – 158° F). Perfect for industrial environments and non-climate-controlled installations. Coupled with an IP30 rated metal enclosure with shock and vibration protection, the TI-RG262i is suitable for a wide variety of gigabit and fiber SPF long-distance networking installations, including industrial and manufacturing sites, offsite management facilities, warehousing, parking garages, and more.
With an easy-to-use web-based management interface and L2 management features, administrators can route and optimize traffic, troubleshoot, use SNMP monitoring and other advanced network controls. VLAN grouping, QoS and per-port bandwidth managed switch controls simplify network organization and optimization.
TI-RG262i Specs and Features:
- Device Interface
- 24 x Gigabit ports
- 2 x Gigabit SFP ports
- 1 x Console port (RJ-45)
- Fixed 2-pin power terminal
- LED indicators
- Standards: IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.1ax, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az
- Data Transfer Rate:
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit Ethernet: 2000Mbps (full duplex)
- SFP: 2000Mbps (full duplex)
- Performance:
- Switch fabric: 52Gbps
- Data RAM buffer: 512KB
- MAC address table: 8K entries
- Jumbo frames: 10KB
- Forwarding mode: store and forward
- Forwarding rate: 38.7Mpps (64-byte packet size)
- Management:
- HTTP web-based GUI
- CLI: Telnet / SSHv2
- SNMP v1, v2c, v3
- SNMP trap (up to 5 receivers)
- RMON groups 1/2/3/9
- Device configuration backup & restore, upgrade firmware, reboot, and reset to default
- Multiple administrative or read-only user accounts
- Enable or disable power saving mode per port
- Static MAC entries
- Static unicast entries
- LLDP (Link layer discovery protocol)
- Netlite device map
- ONVIF device discovery
- SNTP
- SMTP alert
- Syslog
- Port statistics/utilization
- Traffic monitor
- Port mirror: one to one, many to one
- Storm control: Broadcast, multicast, destination lookup failure (Min. limit: 1pps)
- Loopback detection
- DHCP relay/option 82
- Modbus/TCP
- ERPS (Ethernet Ring Protection Switching) G8032v2
- MIB:
- MIB II RFC 1213
- Bridge MIB RFC 1493
- RMON (Group 1,2,3,9) RFC 2819 RFC 1757
- Spanning Tree:
- IEEE 802.1d STP (spanning tree protocol)
- IEEE 802.1w RSTP (rapid spanning tree protocol)
- BPDU filter, guard, and root guard
- Link Aggregation:
- Static link aggregation and 802.1ax/802.3ad dynamic LACP (Up to 8 groups)
- Quality of Service (QoS)
- 802.1p Class of service (CoS)
- DSCP (Differentiated Services Code Point)
- Bandwidth control per port
- Queue Scheduling: strict priority (SP), weighted round robin (WRR), weighted fair queuing (WFQ)
- VLAN:
- 802.1Q tagged VLAN
- MAC-based VLAN
- Port isolation
- Up to 256 VLAN groups, ID range 1-4094
- Multicast:
- IGMP snooping v1, v2, v3
- IGMP querier
- IGMP fast/immediate leave
- Up to 256 multicast groups
- Static multicast entries
- Access Control:
- 802.1X authentication (Local user database, RADIUS, guest VLAN assignment)
- DHCP snooping/screening
- Trusted host/IP access list for management access
- Port Security/MAC address learning restriction (Up to 100 entries per port)
- Static/dynamic ARP inspection
- ACL:
- Source/Destination MAC address
- Source/Destination IP address
- Source Interface
- VLAN ID
- EtherType
- TCP/UDP port 1-65535
- Special Features:
- Netlite device discovery and map display in GUI
- Port security: MAC address learning restriction per port
- DHCP relay/option 82 & DHCP server snooping/screening support
- Wide operating temperature range
- Surge and ESD protection
- Power:
- Power terminal input: 48 – 57V DC
- Compatible power supply: TI-S15052
- Max. Consumption: 20W
- Terminal Block
- Power input, 2 pin
- Wire range: 1.5 mm^2 to 2.5 mm^2
- Solid wire (AWG): 12-18
- Stranded wire (AWG): 12-18
- Wire strip length: 10-11mm
- Enclosure:
- IP30 rated metal enclosure
- Fanless passive cooling
- Rack mountable 1U
- Grounding point
- ESD (Ethernet) Protection: 8KV DC (Air) 4KV (Contact)
- Surge (Power) Protection: 1KV DC
- Operating Temperature: -40° – 70° C (-40° – 158° F
- Dimensions: 440 x 284 x 44mm (17.32 x 11.18 x 1.7 in.)
- Weight: 3.46kg (7.62 lbs.)
- Certifications: CE, FCC, Shock (IEC 60068-2-27), Freefall (IEC 60068-2-31), Vibration (IEC 60068-2-6)
- Package Includes
- 1x TI-RG262i
- Quick Installation Guide
- Console cable (RJ-45 to RS-232)
- Rackmount kit
- Lifetime Manufacturer's Warranty
