About the product
The TRENDnet 5 Port Gigabit PoE++ Powered Managed Switch with PoE Passthrough is an industrially hardened, IP30 rated gigabit PoE++ switch that can withstand extreme indoor environments ranging from -40°C up to 75°C, including industrial and high-traffic commercial environments. Provides up to 90W of PoE++ power to connected devices with no need for additional injectors or external power solutions. Ideal for systems like PTZ cameras, high-gain wireless access points, VoIP handsets, and other advanced security products that require higher electrical output over Cat6A or better cabling.
PoE++ power pass-through allows a single line of PoE++ cabling to power up to 4 devices without any external power options or additional AC power inputs. Simplified plug-and-play operation allows users or installers to expand PoE++ powered networks and security systems without complicated equipment retrofits or installation costs.
TPE-B541 Specs and Features
- Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
- Device Interface: 1 x Gigabit PoE++ in port, 4 x Gigabit PoE+ out port, LED indicators, DIN-Rail mount, Wall mount, Grounding point, Data Transfer Rate
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit: 2000Mbps (full duplex)
- Data RAM Buffer: 128KB
- Switching Fabric: 10Gbps
- MAC Address Table: 2K entries
- Jumbo Frame: 9KB
- Forwarding rate: 7.44Mpps (64-byte packet size)
- PoE++ Powered (90W)
- Hardened components rated for extreme temperatures
- Auto-Negotiation
- Power: IEEE 802.3bt Type 4 (90W), IEEE 802.3bt Type 3 (60W), or IEEE 802.3at (30W), PoE input only (no external power supply), IEEE 802.3bt Type 4 PoE PD Class 7, IEEE 802.3bt Type 3 PoE PD Class 5, IEEE 802.3at Type 2 PoE PD Class 4, IEEE 802.3af Type 1 PoE PD Class 0, Max. consumption: 3.9W (no PoE)
- PoE:
- 65W PoE budget with IEEE 802.3bt Type 4 (90W) input power
- 50W PoE budget with IEEE 802.3bt Type 3 (60W) input power
- 21W PoE budget with IEEE 802.3at (30W) input power
- MTBF: 537,083 hours @ 25°C
- Housing: IP30 metal case, DIN-Rail mount, Wall mount, Grounding point
- Operating Temperature: -40° – 75° C (-40° – 167° F)
- Operating Humidity: Max. 95% non-condensing
- Dimensions: 102 x 80 x 31mm (4.01 x 3.14 x 1.22 in.)
- Weight: 160g (0.35 lb.)
- Certifications: CE, FCC, LVD, IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
- Warranty: Lifetime Manufacturer's Warranty
Technical Specifications
The TRENDnet 5 Port Gigabit PoE++ Powered Managed Switch with PoE Passthrough is an industrially hardened, IP30 rated gigabit PoE++ switch that can withstand extreme indoor environments ranging from -40°C up to 75°C, including industrial and high-traffic commercial environments. Provides up to 90W of PoE++ power to connected devices with no need for additional injectors or external power solutions. Ideal for systems like PTZ cameras, high-gain wireless access points, VoIP handsets, and other advanced security products that require higher electrical output over Cat6A or better cabling.
PoE++ power pass-through allows a single line of PoE++ cabling to power up to 4 devices without any external power options or additional AC power inputs. Simplified plug-and-play operation allows users or installers to expand PoE++ powered networks and security systems without complicated equipment retrofits or installation costs.
TPE-B541 Specs and Features
- Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
- Device Interface: 1 x Gigabit PoE++ in port, 4 x Gigabit PoE+ out port, LED indicators, DIN-Rail mount, Wall mount, Grounding point, Data Transfer Rate
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit: 2000Mbps (full duplex)
- Data RAM Buffer: 128KB
- Switching Fabric: 10Gbps
- MAC Address Table: 2K entries
- Jumbo Frame: 9KB
- Forwarding rate: 7.44Mpps (64-byte packet size)
- PoE++ Powered (90W)
- Hardened components rated for extreme temperatures
- Auto-Negotiation
- Power: IEEE 802.3bt Type 4 (90W), IEEE 802.3bt Type 3 (60W), or IEEE 802.3at (30W), PoE input only (no external power supply), IEEE 802.3bt Type 4 PoE PD Class 7, IEEE 802.3bt Type 3 PoE PD Class 5, IEEE 802.3at Type 2 PoE PD Class 4, IEEE 802.3af Type 1 PoE PD Class 0, Max. consumption: 3.9W (no PoE)
- PoE:
- 65W PoE budget with IEEE 802.3bt Type 4 (90W) input power
- 50W PoE budget with IEEE 802.3bt Type 3 (60W) input power
- 21W PoE budget with IEEE 802.3at (30W) input power
- MTBF: 537,083 hours @ 25°C
- Housing: IP30 metal case, DIN-Rail mount, Wall mount, Grounding point
- Operating Temperature: -40° – 75° C (-40° – 167° F)
- Operating Humidity: Max. 95% non-condensing
- Dimensions: 102 x 80 x 31mm (4.01 x 3.14 x 1.22 in.)
- Weight: 160g (0.35 lb.)
- Certifications: CE, FCC, LVD, IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
- Warranty: Lifetime Manufacturer's Warranty
