About the product
Featuring an AMD Ryzen V1000 series V1500B quad-core processor that delivers great system performance with up to quad-core / 8 threads and Turbo Core up to 2.2 GHz. The TS-673A features two 2.5GbE RJ45 ports and two PCIe Gen 3 slots for you to flexibly deploy 5GbE/10GbE networks. Two M.2 NVMe SSD slots for Qtier Technology and SSD Caching enable constant storage optimization. The TS-673A supports QTS and QuTS hero, allowing users to flexibly switch operating system based on their requirements.
Technical Specifications
| Primary Information | |
| Storage Device Type: | Network Attached Storage |
| Cabinet Form Factor: | Tower |
| Processor / Manufacturer: | AMD |
| Processor / Type: | AMD Ryzen Embedded |
| Processor / Clock Speed: | 2.2 GHz |
| Processor / Number: | V1500B |
| Multi-Core Technology: | Quad-Core |
| RAM / Technology: | DDR4 |
| RAM / Total Installed Size: | 8 GB |
| RAM / Max Supported Size: | 64 GB |
| Data Link Protocol: | Gigabit Ethernet |
| Service & Support Type: | 3-year warranty |
| Features: | AMD RYZEN V1000 SERIES V1500B 4C/8T 2.2GHZ, 8GB DDR4 RAM (2 X SODIMM SLOTS, MAX. 64GB, OPTIONAL ECC RAM SUPPORT), 2X M.2 NVME PCIE GEN3 SSD SLOTS, 2 X 2.5GBE LAN, OPTIONAL 10GBE EXPANSION VIA A PCIE, 2 X PCIE 3.0 X 4 SLOTS, USB 3.2 GEN2 TYPE-C & TYPE-A BU |
| Processor | |
| Cache Memory Type: | L3 Cache |
| Cache Memory Installed Size: | 4 MB |
| RAM | |
| RAM / Installed Qty: | 1 |
| RAM / Total Slots Qty: | 2 |
| Storage | |
| Hard Drive / Size: | 3.5; M.2 |
| Hard Drive / Interface Type: | Serial ATA |
| Hard Drive / Bays Qty: | 6 |
| Storage Controller | |
| Storage Controller Type: | PCIe NVMe |
| Expansion | |
| Interfaces & Connections: | 2 X 2.5GBE LAN;3 x Type-A USB 3.2 Gen 2 10Gbps;1 x Type-C USB 3.2 Gen 1 5Gbps |
| Power | |
| Power / Device Type: | Power Supply |
| Power / Voltage Required: | 100-240V AC, 50-60Hz |
| Power / Provided (W): | 250 Watt |
