Qnap Ts-855X - Nas Server

Name: Qnap Ts-855X - Nas Server
Brand: Qnap
SKU: T935217
Price: 2430.43 CAD
Availability: InStock

$2,430.43 CAD

~~$2,673.48 CAD~~ $2,430.43 CAD

-9% OFF Ask for quote

Shipping calculated at checkout.

Qnap Desktop 8-Bay Nas/Iscsi Ip-San, Intel Atom C5125 Processor, 8 Gb Ddr4 Ram, 2.5Gbe (Rj-45), 10Gbase-T, M.2 2280 Pcie Gen3 X4 Slots, Pcie Gen3 X4

VPN:TS-855X-8G-US SKU:T935217 UPC:885022026357

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

About the product

The high-capacity TS-855X has six 3.5-inch SATA drive bays, two 2.5-inch SATA drive bays (for SSDs) and an 8-core processor supporting Intel QuickAssist Technology (QAT), greatly assisting businesses in deploying a data storage and virtualization environment. The built-in 10GbE/2.5GbE high-speed connectivity helps realize fast data access, backup/restoration, file server, and virtualization applications. Running the QTS operating system as standard, the TS-855X can be switched to use the ZFS-based QuTS hero operating system based on your requirements.

Technical Specifications

Primary Information
Product Description:	QNAP TS-855X - NAS server
Device Type:	NAS server
Host Connectivity:	2.5 Gigabit Ethernet / 10 Gigabit Ethernet
Installed Devices / Modules Qty:	0 (installed) / 8 (max)
Dimensions (WxDxH):	11.5 in x 12.6 in x 9.1 in
Weight:	18.74 lbs ()
Localization:	United States
Processor:	1 x Intel Atom C5125 2.8 GHz (8-core)
Storage Controller:	RAID SATA 6Gb/s RAID RAID 0, 1, 5, 6, 10, 50, JBOD, 60
Networking:	10Mb LAN, 100Mb LAN, 1GbE, 10GbE, 2.5GbE
Performance:	Maximum concurrent connections: 2500 - (with maximum memory) ¦ Maximum pool size: 308 TB ¦ Maximum number of storage pool: 128 ¦ Maximum volume size: 250 TB ¦ Maximum number of volume: 128 ¦ Maximum shared folder size: 250 TB ¦ Maximum number of shared folder: 512 ¦ Maximum LUN size: 250 TB ¦ Maximum number of targets LUN: 128 ¦ Minimum snapshot interval: 5 min ¦ Maximum FTP connection: 1024 ¦ Local user account: 4096 ¦ Local group account: 512 ¦ Domain user/group account: 200000 ¦ Log recording: 3000 events per second ¦ Virtual hosts: 32 ¦ Maximum number of version control: 64
RAM:	8 GB
Power:	AC 100-240 V
Storage Operating System:	QNAP QuTS hero h5.1.0 / QTS 5.1.0
System Requirements:	Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows Server 2022, Microsoft Windows 7 / 8 / 10 / 11, Apple macOS 10.10 or later
Manufacturer Warranty:	3-year warranty
General
Device Type:	NAS server
Host Connectivity:	2.5 Gigabit Ethernet / 10 Gigabit Ethernet
Total Storage Capacity:	0 GB
Installed Devices / Modules Qty:	0 (installed) / 8 (max)
Width:	11.5 in
Depth:	12.6 in
Height:	9.1 in
Weight:	18.74 lbs ()
Built-in Devices:	LED panel, LED display
Localization:	United States
Processor / Memory
Processors Installed:	1 x Intel Atom C5125 2.8 GHz
Number of Cores:	8-core
Max Supported Qty:	1
RAM:	8 GB (installed) / 128 GB (supported) - DDR4
Features:	Supported ECC modules operate in non-ECC mode
Flash Memory Installed:	5 GB
Storage Controller
Type:	RAID
Interface Type:	SATA 6Gb/s
RAID Level:	RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60
Networking
Data Link Protocol:	10Mb LAN, 100Mb LAN, 1GbE, 10GbE, 2.5GbE
Network / Transport Protocol:	PPTP, L2TP, IPSec, WireGuard, QBelt, OpenVPN
Remote Management Protocol:	SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH
Network Services Compatibility:	Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Network File System v3 (NFS v3), Network File System v4 (NFS v4)
Performance:	Maximum concurrent connections: 2500 - (with maximum memory) ¦ Maximum pool size: 308 TB ¦ Maximum number of storage pool: 128 ¦ Maximum volume size: 250 TB ¦ Maximum number of volume: 128 ¦ Maximum shared folder size: 250 TB ¦ Maximum number of shared folder: 512 ¦ Maximum LUN size: 250 TB ¦ Maximum number of targets LUN: 128 ¦ Minimum snapshot interval: 5 min ¦ Maximum FTP connection: 1024 ¦ Local user account: 4096 ¦ Local group account: 512 ¦ Domain user/group account: 200000 ¦ Log recording: 3000 events per second ¦ Virtual hosts: 32 ¦ Maximum number of version control: 64
Features:	Wake on LAN (WOL), RADIUS support, DHCP server, FTP server, Domain Controller, Single Root I/O Virtualization (SR-IOV), file station, port trunking, SSD trim, Windows ODX, hybrid backup sync, Qfiling, Qsirch, SQL Server, McAfee protection, VJBOD Cloud, Qsync, QuMagie, Smart Fan, QmailAgent, QuWAN, LDAP server, Storage Pool, SED Storage Pool, JBOD Expansion, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Disk Roaming, Disk Standby, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, External Device Management, Mount Smart Phone (MTP), Object Storage, shared folder permission, group quota, folder quota, home folder, Resource Monitor, Virtual Switch, Allow/Deny List, Access Protection, Service binding, DA Driver Analyzer, floating point unit, fibre channel service, block-based iSCSI LUN, LUN snapshot, RAID Expansion, Storage Pool Expansion, RAID Hot Spare, SSD life estimation, domain security, security counselor, malware remover, 2-step verification, HybridMount, Hyper Data Protector, Boxafe, Windows ACL, schedule on/off, Secure Erase, QVPN Service, End-to-End Data Integrity, External RAID Device Management, user quota, DDNS (Dynamic Domain Name Service), Encryption Engine
Encryption Algorithm:	256-bit AES, AES-NI
Expansion / Connectivity
Expansion Bays:	6 (total) / 6 (free) x hot-swap - 3.5 ¦ 2 (total) / 2 (free) x hot-swap - 2.5
Expansion Slots:	2 (total) / 2 (free) x PCI Express 3.0 x4 ¦ 2 (total) / 2 (free) x M.2 2280
Interfaces:	3 x USB 3.2 Gen 1 ¦ 1 x USB 2.0 ¦ 1 x Ethernet 10Gb ¦ 2 x 2.5 Gigabit Ethernet
Miscellaneous
Cables Included:	2 x network cable
Features:	Security lock slot (cable lock sold separately), built-in 3 cooling fans, auto-copy function, reset button, dual boot, alarm buzzer
Security Slot Type:	Kensington security slot
Compliant Standards:	FIPS 140-2, TLS v1.2, TLS v1.0, TLS v1.1, TLS v1.3
Included Accessories:	2 x M.2 SSD heatsink, 24 x flat head screws (for 2.5 HDD), 32 x flat head screws (for 3.5 HDD), power cable
