About the product
Delivering performance, versatility and density without compromise, the Cisco UCS B200 M5 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M5 harnesses the power of the latest Intel® Xeon® processor scalable family CPUs with up to 3072 GB of RAM (using 128 GB DIMMs), two solid-state drives (SSDs) or hard disk drives (HDDs), and up to 80 Gbps throughput connectivity.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M5 harnesses the power of the latest Intel® Xeon® processor scalable family CPUs with up to 3072 GB of RAM (using 128 GB DIMMs), two solid-state drives (SSDs) or hard disk drives (HDDs), and up to 80 Gbps throughput connectivity.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- RAID provides data reliability, fault tolerance and improves overall performance
- With 96 GB memory, you can multitask between applications smoothly
Technical Specifications
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| Serial ATA | |
| RAID Supported | Yes |
| I/O Expansions | |
| "Number of Internal 2.5"" Bays" | 2 |
| Number of Total Expansion Bays | 2 |
| Hot Swappable Bays | Yes |
| Memory | |
| Maximum Memory Supported | 3 TB |
| Standard Memory | 96 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 6 |
| Total Number of Memory Slots | 24 |
| Physical Characteristics | |
| Weight (Approximate) | 9.50 lb (4310 g) |
| Form Factor | Blade |
| Height | 1.95" (49.53 mm) |
| Width | 8" (203.20 mm) |
| Depth | 24.40" (619.76 mm) |
| Processor | |
| Processor Speed | 2.30 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 5118 |
| Processor Core | Dodeca-core (12 Core) |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | UCS-SP-B200M5-A1 |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS B200 M5 Server |
| Product Series | B200 M5 |
| Brand Name | Cisco |
