About the product
Delivering performance, versatility and density without compromise, the Cisco UCS B200 M5 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor.
- 40 Gigabit Ethernet for efficient data transfer and fast connectivity
- RAID provides data reliability, fault tolerance and improves overall performance
- 768 GB memory enables you to do multitasking and run intensive applications lag-free
- 480 GB SSD provides ample space for important documents, files and critical data
Technical Specifications
| Network & Communication | |
| Ethernet Technology | 40 Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information |
|
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Controllers | |
| Controller Type | Serial ATA |
| 12Gb/s SAS | |
| RAID Supported | Yes |
| Storage | |
| Solid State Drive Interface | Serial ATA/600 |
| Solid State Drive Configuration | 2 x 240GB |
| Total Solid State Drive Capacity | 480 GB |
| I/O Expansions | |
| "Number of Internal 2.5"" Bays" | 2 |
| Number of Total Expansion Bays | 2 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 2 |
| Physical Characteristics | |
| Weight (Approximate) | 9.50 lb (4309.13 g) |
| Form Factor | Blade |
| Height | 2" (50.80 mm) |
| Width | 8" (203.20 mm) |
| Depth | 24.40" (619.76 mm) |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 1 |
| Number of USB 3.0 Ports | 1 |
| Number of VGA Ports | 1 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | UCSSPB200M5CA |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS B200 M5 Server |
| Product Series | B200 M5 |
| Brand Name | Cisco |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 3 TB |
| Signal Processing | Registered (Buffered) |
| Standard Memory | 768 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 12 |
| Memory Clock Speed | 2.99 GHz |
| Processor | |
| Cache | 38.50 MB |
| Processor Speed | 2.20 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 6238R |
| Processor Core | Octacosa-core (28 Core) |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Generation | 2nd Gen |
