About the product
- Get a wider viewing angle with 5:4 aspect ratio to watch movies or view two documents side by side
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- Enjoy crisp content and energetic hues with the 250 cd/m² brightness
- HDMI interface allows you to connect to a variety of HD devices including gaming consoles, Blu-ray players, laptop PCs, digital cameras and many others for the ultimate true high-definition display
- 5 ms response time makes it excellent for latest action films, sports or gaming
- VESA mount compatibility allows you to mount the display on a wall or with a stand depending on your specific needs
Technical Specifications
| Warranty | |
| Additional Warranty Information | AAC |
| Audio | |
| Speakers | Yes |
| Number of Speakers | 2 |
| Speaker Output Power | 2 W |
| Power Description | |
| Input Voltage Range | 120V to 230V |
| Operating Power Consumption (Energy Star) | 18 W |
| Standby Power Consumption (Energy Star) | 500 mW |
| Off-Mode Power Consumption (Energy Star) | 300 mW |
| Miscellaneous | |
| Package Contents | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| TCO Certified | Yes |
| General Information | |
| Product Type | LED Monitor |
| Manufacturer Part Number | UM.CB6AA.A03 |
| Manufacturer Website Address | http://www.acer.ca |
| Manufacturer | Acer, Inc |
| Product Model | B196L A |
| Product Name | B196L A LED Monitor |
| Product Series | B6 |
| Brand Name | Acer |
| Interfaces/Ports | |
| HDMI | Yes |
| HDMI Version | 1.4 |
| VGA | Yes |
| Headphone | Yes |
| Audio Line Out | Yes |
| Number of VGA Ports | 1 |
| Total Number of HDMI Ports | 1 |
| Number of HDMI 1.4 Ports | 1 |
| Video | |
| Brightness | 250 cd/m² |
| Color Supported | 16.7 Million Colors |
| Maximum Resolution | 1280 x 1024 |
| Color Depth | 6-bit+FRC |
| Standard Refresh Rate | 60 Hz |
| Dynamic Contrast Ratio | 100,000,000:1 |
| Native Contrast Ratio | 1,000:1 |
| Maximum Resolution (HDMI) | 1280x1024@60Hz |
| Maximum Resolution (VGA) | 1280x1024@60Hz |
| Physical Characteristics | |
| Weight (Approximate) | 6.08 lb (2760 g) |
| Height | 13.27" (337 mm) |
| Width | 16" (406.40 mm) |
| Depth | 2.05" (52 mm) |
| Weight with Stand (Approximate) | 11.75 lb (5330 g) |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Height with Stand | 21.03" (534.20 mm) |
| Width with Stand | 16" (406.40 mm) |
| Depth with Stand | 8.70" (221 mm) |
| Color Family | Gray |
| Technical Information | |
| Aspect Ratio | 5:4 |
| Pixel Pitch | 11.57 mil (0.29 mm) |
| Response Time | 5 ms |
| Mount Type | Wall Mountable |
| Screen Surface | Anti-glare |
| Viewable Screen Size | 19" |
| Screen Mode | SXGA |
| Number of Screens | 1 |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Backlight Technology | LED |
| Panel Technology | In-plane Switching (IPS) Technology |
| Curved Screen | No |
| Pivot | No |
| Screen Size Class | 19" |
| Stand Adjustments | Height |
| Swivel | |
| Response Time Details | 5ms GTG |
| Active Display Area (mm) | 376x301 |
| Cover Glass | No |
