About the product
The Uninterruptible Power Supply (UPS) shall be powered by 24VDC (nominal) input and provide 24VDC (nominal) output at 100 Watts (max.) for a duration of 1.0 minutes, typ. Ultracapacitors shall be employed for energy storage instead of rechargeable batteries, for maintenance-free operation. Remote device management shall be provided via Ethernet interface and multiple source, platform independent software withSNMP v1/v2c/v3 capability. The UPS shall have the ability to monitorload current and predict Hold Time in single or dual power supply applications. The UPS shall monitor and report temperature to predict changes in capacity over its lifetime. The UPS shall offer DIN rail mounting and UL508 approval for integration into NEMA controlpanels or equipment cabinets.
- Provides backup power to devices that require DC input while the incoming power is lost
- 100 W load capacity - backup power for your valuable electronics
Technical Specifications
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Network Management | SNMP |
| Miscellaneous | |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Power Description | |
| Input Voltage | 24 V DC |
| Output Voltage | 24 V DC |
| Input Voltage Range | 24 V DC - 28 V DC |
| Load Capacity (Watt) | 100 W |
| Physical Characteristics | |
| Weight (Approximate) | 2.18 kg |
| Form Factor | DIN Rail |
| Height | 5.62" (142.70 mm) |
| Width | 5.46" (138.60 mm) |
| Depth | 6.91" (175.50 mm) |
| General Information | |
| Product Type | DC UPS |
| Manufacturer Part Number | UPS00100DC |
| Manufacturer Website Address | http://www.panduit.com |
| Manufacturer | PANDUIT CORP |
| Product Model | UPS00100DC |
| Product Name | Industrial Network Uninterruptible Power Supply (UPS) |
| Brand Name | Panduit |
| Technical Information | |
| Application/Usage | HMI |
| Control Panel | |
| Network | |
| Programmable Logic Controller (PLC) | |
| Switch | |
| Industry | |
| Overload Protection | Yes |
