About the product
This USB 3.0 dock combines three USB 3.0 ports, headphone and microphone audio connectors, and a Gigabit Ethernet RJ45 port, into a single docking station for maximum productivity.
Display Adaptability
Offering flexible dual video combinations right out-of-the-box, this universal laptop docking station features HDMI, DVI and VGA external monitor outputs. Each video output supports HD video resolutions (2048x1152 max) and HD video playback for an ideal solution to expanding your notebook's video capability.
Available display combinations:
- HDMI + VGA
- HDMI + DVI
Integrated USB Hub
The built-in USB hub features three USB 3.0 ports for connecting extra peripherals such as external hard drives or a wired mouse, as if they are connected directly to your laptop.
Direct Ethernet Connectivity
The integrated RJ45 Ethernet port supports speeds of 10/100/1000 Mbps, giving you an instant connection to a wired network.
StarTech.com laptop docking stations can be used for cost savings and faster deployment with just a single cable. This USB 3.0 Docking Station is backed by a competitive 3-year warranty and free lifetime Technical Support.
More from the Manufacturer
- UNIVERSAL DUAL MONITOR DOCKING STATION: USB 3.0 docking station features HDMI, VGA, and DVI outputs for broad display compatibility; Supports up to 1920x1080 (HDMI), 1920x1200 (DVI-D), and 2048x1152 (VGA); This dual monitor dock is TAA compliant
- INCREASED PRODUCTIVITY: This dual monitor docking station combines 3x USB 3.2 Gen 1 (5Gbps) ports, headphone & mic audio jack, and a Gigabit Ethernet RJ45 port into a single IT-grade dock; Connect directly to older VGA and DVI monitors without adapters
- VERSATILE DESIGN: The high performance dock features a sleek design that is the ideal addition to any home or office workstation; This dock enhances your laptop's capabilities while taking up little desk space; Includes 3ft (0.9m) USB 3.2 Gen 1 host cable
- UNIVERSAL COMPATIBILITY: Compatible with Windows, macOS, & ChromeOS, enabling extended dual displays on laptops, Chromebooks and MacBooks that feature a USB-A host connection such as X1 Carbon, ThinkPad, Latitude, Precision, XPS 15, Spectre, and ZBook
- CONNECTIVITY TOOLS: Optimize the performance and security of this docking station, using the included MAC Address Changer, USB Event Monitoring, Windows Layout & Wi-Fi Auto Switch utilities (available for download)
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Power Description | |
| Power Source Type | Power Adapter |
| Miscellaneous | |
| Compatibility | Compatible with Windows, macOS, & ChromeOS, enabling extended dual displays |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Physical Characteristics | |
| Weight (Approximate) | 10.41 oz (295 g) |
| Length | 11.97" (304 mm) |
| Height | 1.73" (44 mm) |
| Width | 7.01" (178 mm) |
| Product Color | Black |
| Color Family | Black |
| General Information | |
| Product Type | Docking Station |
| Manufacturer Part Number | USB3SDOCKHDV |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | Dual-Monitor USB 3.0 Docking Station with HDMI &DVI/VGA |
| Brand Name | StarTech.com |
| Technical Information | |
| Cable Length | 3 ft (0.90 m) |
| Device Supported | Notebook |
| Connectivity Technology | Wired |
| Features | Cable Lock Slot |
| Number of Displays Supported | 2 |
| Supported Resolutions | 2048 x 1152 |
| 1920 x 1200 | |
| 1920 x 1080 | |
| Screen Mode Supported | HD |
| Interfaces/Ports | |
| Host Interface | USB 3.0 |
| Microphone | Yes |
| HDMI | Yes |
| DVI | Yes |
| VGA | Yes |
| Headphone | Yes |
| Network (RJ-45) | Yes |
| Audio Line Out | Yes |
| Number of HDMI Outputs | 1 |
| Total Number of USB Ports | 4 |
| Headphone/Microphone Combo Port | Yes |
| Number of RJ-45 Ports | 1 |
| Number of USB Type-A Ports | 3 |
| USB Type-A | Yes |
| Software | |
| Operating System Supported | Mac OS X 10.6 Snow Leopard |
| Windows 11 | |
| Windows 7 | |
| Windows 8 | |
| Windows 8.1 | |
| Windows 10 | |
| macOS 14 | |
| Mac OS X 13.0 Ventura | |
| Mac OS X 12.0 Monterey | |
| Windows Vista | |
| ChromeOS 69+ | |
| Mac OS X 10.12 Sierra | |
| Mac OS X 10.14 Mojave | |
| Mac OS X 10.15 Catalina | |
| Windows XP SP3 | |
| Mac OS X 11.0 Big Sur |
