About the product
UTC-220 features one-piece solution and fan-less design that easy to embedded into kiosk chassis or wall mount type. Continuation of the advantage from UTC series, It is easy to integrate key peripherals and display systems for diversified self-service and interactive signage deploy in different application areas. The systems deliver updated information with well-designed interactive interfaces, fully ensure relevant content and targeted promotions are delivered.
- Available for embedded into kiosk chassis and wall mount type
- One-piece and fan-less design
- Rich screen size and core from UTC series
- Rich IO for extensional peripherals connection
- Built-in Intel® Celeton® J1900 (UTC-220D)
- Built-in Intel® Core™ i5-6300U (UTC-220F)
- Built-in Intel® Pentium® N4200 (UTC-220G)
- Providing Natural Viewing Experience with 21.5" Display
- Could be take as monitor only
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Power Description | |
| Maximum Power Supply Wattage | 84 W |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Display & Graphics | |
| Screen Resolution | 1920 x 1080 |
| Screen Size | 21.5" (546.10 mm) |
| Screen Mode | Full HD |
| Memory | |
| Maximum Memory Supported | 16 GB |
| Standard Memory | 4 GB |
| Memory Technology | DDR3L SDRAM |
| Total Number of Memory Slots | 2 |
| Interfaces/Ports | |
| HDMI | Yes |
| VGA | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Physical Characteristics | |
| Weight (Approximate) | 12.79 lb (5800 g) |
| Form Factor | Desktop |
| Height | 12.24" (310.91 mm) |
| Width | 20.28" (515.04 mm) |
| Depth | 1.66" (42.20 mm) |
| Processor | |
| Processor Speed | 2.40 GHz |
| Processor Type | Core i5 |
| Processor Model | i5-6300U |
| Processor Core | Dual-core (2 Core) |
| Processor Manufacturer | Intel |
| Processor Generation | 6th Gen |
| General Information | |
| Product Type | All-in-One Computer |
| Manufacturer Part Number | UTC-220FP-ATO0E |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | UTC-220 |
| Product Name | UTC-220 All-in-One Computer |
| Product Series | UTC-200 |
| Brand Name | Advantech |
