About the product
UTC-315 is the multi-purpose all-in-one computing system which equipped with wide format, touch based LCD panel. It is easy to integrate key peripherals and display systems for diversified self-service and interactive signage deploy in different application areas. With the removable frame, the system also could fulfill industries or control system applications with panel mounting design. UTC series touch panel computers are the best investments to enhance user satisfaction, further brand equity, and maximize business profits.
- Digital Signage Display - Ideal for rack, passageway, booth or display counter
- 15.6" (396.24 mm) - Perfect for showing special recordings, educational messages, pennants and engaging video files in 1366 x 768 resolution
- Experience luminescent visual images with LCD display
- Experience responsive performance, power and adaptability with Intel Celeron 2 GHz processor
Technical Specifications
| Memory | |
| Standard Memory | 4 GB |
| Network & Communication | |
| Ethernet | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Video | |
| Brightness | 220 cd/m² |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Processor & Chipset | |
| Processor Speed | 2 GHz |
| Processor Type | Celeron |
| Processor Core | Quad-core (4 Core) |
| Display & Graphics | |
| Pixel Pitch | 9.92" (252 mm) |
| Display Resolution | 1366 x 768 |
| Screen Size | 15.6" (396.24 mm) |
| Touchscreen | Yes |
| Display Screen Type | LCD |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Number of USB 2.0 Ports | 5 |
| Number of USB 3.0 Ports | 1 |
| Serial | Yes |
| Physical Characteristics | |
| Height | 10.24" (260 mm) |
| Width | 15.83" (402 mm) |
| Depth | 1.56" (39.70 mm) |
| VESA Mount Standard | 75 x 75 |
| Product Color | Black |
| General Information | |
| Product Type | Digital Signage Display |
| Manufacturer Part Number | UTC-315DP-ATB0E |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | UTC-315DP-ATB0E |
| Product Name | UTC-315D 15.6" Ubiquitous Touch Computer with Intel Celeron J1900 |
| Product Series | UTC-300 |
| Brand Name | Advantech |
