About the product
The VID2VGATV2 Composite and S-Video to VGA Video Scan Converter (with Scaler) provides a simple way to convert Composite or S-Video signals to VGA (or Component RCA) output, for use with computer monitors, projectors or HDTV sets. Equipped with an On-Screen Display (OSD) menu and dip switches for simple configuration and selection of your video output settings
this compact video scaler installs quickly and easily for a true plug-and-play experience. An integrated scaler circuit dynamically converts the S-Video or Composite video input signal, giving you multiple output resolutions to choose from, to ensure compatibility with your display or projector. Plus, the Component/S-Video-VGA Converter includes a VGA to Component (RCA) breakout cable, which enables you to connect to TV sets that are not equipped with a VGA port. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer More from the ManufacturerConvert and scale Composite/S-Video input to VGA/Component outputAccepts NTSC and PAL inputOn-Screen Display for simple output setting selectionVGA to Component (YPbPr) RCA Adapter included50 Hz to 60 Hz frame rate conversionPlug & Play installation - no drivers or software required
Technical Specifications
| Interfaces/Ports | |
| VGA | Yes |
| S-Video | Yes |
| Composite Video | Yes |
| Number of S-Video Inputs | 1 |
| Number of VGA Outputs | 1 |
| Number of Composite Video Inputs | 1 |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| General Information | |
| Product Type | Signal Converter |
| Manufacturer Part Number | VID2VGATV2 |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | Composite and S-Video to VGA Video Scan Converter |
| Brand Name | StarTech.com |
| Physical Characteristics | |
| Weight (Approximate) | 3.03 oz (86 g) |
| Form Factor | External |
| Length | 4.40" (111.76 mm) |
| Height | 1" (25.40 mm) |
| Width | 2.50" (63.50 mm) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Platform Supported | PC |
| Functions | Signal Conversion |
| Video Scaling | |
| Video Formats | HDTV |
| Maximum Resolution | 1600 x 1200 |
| Analog Signal | Yes |
| Video Signal Format | NTSC |
| PAL |
