Rack Equipments

Expected delivery 3 to 7 business days (exceptions applied)

Vertiv

Vertiv Geist rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU - Monito

Vertiv Geist rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU - Monito

Regular price $3,618.95 CAD
Regular price $4,053.22 CAD Sale price $3,618.95 CAD
-10% OFF Ask for quote
Shipping calculated at checkout.
Vertiv Geist rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU - Monitored - IEC 60309 3P+N+E (IP44) - 30 x U-Lock IEC 60320 C13, 12 x U-Lock IEC 60320 C19 - 230 V AC - Overcurrent Protection, Single Pole - Network (RJ-45) - 10 ft (3.05 m) Cord Length - Vertical - Rack-mountable

VPN:VP4N50A0 SKU:RSC555957 UPC:

  • PDU provides active metering enabling energy optimization and circuit protection
  • PDU distributes AC power to multiple servers and balances the load on the servers
  • With monitored PDU, you can remotely monitor single-or three-phase voltage easily

Volume discount available - Ask for quote..

View full details

Recently Viewed

Vertiv Geist rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU - Monito

Product information summary

Vertiv Geist rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU - Monito

About the product

Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain realtime environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs. Upgradeable Outlet Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of outlet level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.

Benefits

  • Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a breakin the network chain occurs. Supports up to 40 rPDUs.
  • Every unit is 100% tested for reliability and functionality.
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.
  • PDU provides active metering enabling energy optimization and circuit protection
  • PDU distributes AC power to multiple servers and balances the load on the servers
  • With monitored PDU, you can remotely monitor single-or three-phase voltage easily
  • Before critical input source become overloaded always be warned with monitored PDUs

Technical Specifications

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Interfaces/Ports
Network (RJ-45)Yes
Management
Management
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
  • TACACS+
  • Modbus TCP
  • CSV datalog
  • JSON API
  • JSON datalog
Warranty
Additional Warranty Information

5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years

Miscellaneous
Application/UsageIT Equipment
Package Contents
  • rPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU
  • Vertical Mounting Bracket Kit
Certifications & Standards
  • UL
  • c-UL Listed 62368-1
  • FCC Part 15 Class A
Country of OriginUnited States
TAA CompliantYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
General Information
Product TypePDU
Manufacturer Part NumberVP4N50A0
Manufacturer Website Addresshttp://www.vertiv.com/
ManufacturerVertiv
Product ModelMN05M9W1-42PTB3-5PS56B0A10-S
Product NamerPDU MN05M9W1-42PTB3-5PS56B0A10-S 42-Outlets PDU
Product SeriesrPDU
Brand NameVertiv Geist
Physical Characteristics
Length72" (1828.80 mm)
Mount TypeRack-mountable
Cord Length10 ft (3.05 m)
Width2" (50.80 mm)
Depth2" (50.80 mm)
Mounting OrientationVertical
Product ColorBlack Powder Coat
Color FamilyBlack
Power Description
Circuit BreakerYes
Input Voltage230 V AC
Output Voltage208 V AC
Input Current40 A
Input Voltage Range200 V AC - 240 V AC
346 V AC - 415 V AC
Input Frequency60 Hz
Power Rating (Watt)28.80 kW
Technical Information
FeaturesLED Display
Protection TypeSingle Pole
Overcurrent Protection
Plug/Connector TypeIEC 60309 3P+N+E (IP44)
PhaseThree Phase
Receptacle TypeU-Lock IEC 60320 C13
U-Lock IEC 60320 C19
Load Capacity (Watt)28.80 kW
PDU TypeMonitored
Receptacle Detail12 x U-Lock IEC 60320 C19
30 x U-Lock IEC 60320 C13
Plug/Connector Detail1 x IEC 60309 3P + N + E (IP44)
