Extreme Networks Virtual Services Platform 4900 Series Vsp4900-12M

Name: Extreme Networks Virtual Services Platform 4900 Series Vsp4900-12M
Brand: Extreme
SKU: T173405
Price: 25548.48 CAD
Availability: InStock

$25,548.48 CAD

~~$28,103.33 CAD~~ $25,548.48 CAD

-9% OFF Ask for quote

Shipping calculated at checkout.

Extreme Networks Virtual Services Platform 4900 Series Vsp4900-12Mxu-12Xe - Switch - 12 Ports - Managed - Rack-Mountable

VPN:VSP4900-12MXU-12XE SKU:T173405 UPC:644728045068

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Extreme Networks Virtual Services Platform 4900 Series Vsp4900-12M

About the product

The Virtual Services Platform (VSP) 4900 Series is the next generation of Extreme Fabric Connect fixed-form factor switches designed for network edge and aggregation deployments. Providing high-performance, resilient and secure Gigabit/multi-Gigabit Ethernet connectivity, the VSP 4900 enables end-to-end fabric services from network edge to aggregation to core, along with transparent extension of fabric services to the branch. Its advanced capabilities enable full-featured network virtualization to be flexibly deployed across a range of network environments.

Technical Specifications

Primary Information
Product Description:	Extreme Networks Virtual Services Platform 4900 Series VSP4900-12MXU-12XE - switch - 12 ports - managed - rack-mountable
Device Type:	Switch - 12 ports - L3 - managed
Enclosure Type:	Front to back airflow rack-mountable 1U
Subtype:	10 Gigabit Ethernet
Ports:	12 x 100/1000/2.5G/5G/10GBase-T (PoE+) + 12 x 1 Gigabit / 10 Gigabit SFP+
MAC Address Table Size:	80K entries
Routing Protocol:	RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, PIM-SM, IGMPv3, OSPFv3, PIM-SSM, RIPng, BGP+
Features:	Full duplex capability, auto-negotiation, ARP support, VLAN support, port mirroring, DPI, sFlow, MSTP support, QoS, LACP, RSPAN, VRF, IPFIX, 3 fans, SPB, VXLAN, port-based VLAN, VSN support, support IP Shortcut Routing, RSTP, MLT for subscriber lines, MACsec, LRM optics support
Compliant Standards:	IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ah, IEEE 802.1ag, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1aq, IEEE 802.3bm, IEEE 802.1Qbp, IEEE 802.1Qcj
Power:	AC 120/230 V (50 - 60 Hz)
Power Redundancy:	Optional
Dimensions (WxDxH):	17.3 in x 19.2 in x 1.7 in
Weight:	16.71 lbs
System Requirements:	VSP Operating System Software (VOSS)
Manufacturer Warranty:	1-year warranty
General
Device Type:	Switch - 12 ports - L3 - managed
Enclosure Type:	Front to back airflow rack-mountable 1U
Subtype:	10 Gigabit Ethernet
Ports:	12 x 100/1000/2.5G/5G/10GBase-T (PoE+) + 12 x 1 Gigabit / 10 Gigabit SFP+
MAC Address Table Size:	80K entries
Routing Protocol:	RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, PIM-SM, IGMPv3, OSPFv3, PIM-SSM, RIPng, BGP+
Features:	Full duplex capability, auto-negotiation, ARP support, VLAN support, port mirroring, DPI, sFlow, MSTP support, QoS, LACP, RSPAN, VRF, IPFIX, 3 fans, SPB, VXLAN, port-based VLAN, VSN support, support IP Shortcut Routing, RSTP, MLT for subscriber lines, MACsec, LRM optics support
Compliant Standards:	IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ah, IEEE 802.1ag, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1aq, IEEE 802.3bm, IEEE 802.1Qbp, IEEE 802.1Qcj
Processor:	1
RAM:	2 GB
Flash Memory:	8 GB
Expansion / Connectivity
Interfaces:	2 x USB ¦ 1 x serial (console) RJ-45 management ¦ 1 x 1000Base-T RJ-45 management ¦ 1 x console (micro-USB) Type A ¦ 12 x 1/10GBase-X SFP+ ¦ 12 x 100/1000/2.5G/5G/10G RJ-45
Expansion Slots:	1 (total) / 0 (free) x Versatile Interface Module (VIM)
Power
Power Device:	Internal power supply - hot-plug
Power Redundancy:	Optional
Power Redundancy Scheme:	1+1 (with optional power supply)
Voltage Required:	AC 120/230 V (50 - 60 Hz)
Miscellaneous
Rack Mounting Kit:	Included
Compliant Standards:	BSMI, EN 61000-3-2, SABS, EN 61000-3-3, EN55024, CB, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, CDRH, VCCI Class A, EAC, GB 9254, EN 300 386 V1.6.1, RoHS 2011/65/EU, EN 55011 class A, CISPR 11 class A, WEEE 2012/19/EU, EMC 2014/30/EU, FCC CFR47 Part 15 B Class A, LVD 2014/35/EU, GB 4943.1-2011, IEC/EN 61000-4-3, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, CNS 14336-1, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, ETSI EN 300 019-2-3 V2.1.2, ETSI EN 300 019-2-2 V2.1.2, NRCS, EN/ETSI 300 019-2-1 v2.1.2, EN/ETSI 300 753, ASTM D3580, CISPR 24:2010 Class A, ACMA RCM, CISPR 32 Class A, EN 60825-1 Class 1, CAN/CSA-C22.2 No. 62368-1, CAN/CSA-C22.2 No. 60950-1, UL 62368-1, China RoHS SJ/T 11363-2006, RoHS CNS 15663, FCC CFR21 Part 1040.10, AS/NZS CISPR 32
Software / System Requirements
OS Required:	VSP Operating System Software (VOSS)
Dimensions & Weight
Width:	17.3 in
Depth:	19.2 in
Height:	1.7 in
Weight:	16.71 lbs
