About the product
Multi-mode three-phase rack mount UPS (5 to 60kW N+1)
The Eaton BladeUPS is a revolutionary power quality solution, expanding power protection from 5 kW to 60 kW in a single industry standard 19-inch rack, and, most significantly, providing this robust, compact solution without generating the additional heat associated with legacy end-of-row, modular UPS products.
- Achieves the highest power density in the marketplace
- Requires only six rack units (6U) per unit
- Reduces single points of failure with an intelligent bypass design that eliminates human error
- Provides the ultimate in reliability through a peer-to-peer paralleling relationship
Technical Specifications
| Environmental Conditions | |
| Thermal Dissipation | 12282 BTU/h |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Network Management | Web/SNMP/Modbus TCP |
| Miscellaneous | |
| TAA Compliant | Yes |
| Technical Information | |
| Application/Usage | Small Computer Room |
| Phase | Three Phase |
| Receptacle Type | Hardwired MBM |
| Receptacle Detail | 1 x Hardwired MBM |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Battery Capacity | 5000 mAh |
| Number of Batteries | 120 |
| Backup/Run Time (Full Load) | 4.70 Minute |
| Battery Characteristics | Hot-swappable/Sealed |
| DC System Voltage | 240 V DC |
| Physical Characteristics | |
| Weight (Approximate) | 1392 lb (631400.58 g) |
| Form Factor | Rack-mountable |
| Rack Height | 42U |
| Height | 80" (2032 mm) |
| Width | 24" (609.60 mm) |
| Depth | 42" (1066.80 mm) |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | ZP2231500XXX100 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Name | BladeUPS 36KVA Rack-mountable UPS |
| Product Line | BladeUPS |
| Brand Name | Eaton |
| Power Description | |
| Input Voltage | 120 V AC |
| 208 V AC | |
| Output Voltage | 208 V AC |
| 180 V AC | |
| 228 V AC | |
| Waveform Type | Sine Wave |
| Output Frequency | 60 Hz |
| Load Capacity (VA) | 36 kVA |
| Load Capacity (Watt) | 36 kW |
| Output Power Factor | 1 |
