Acerca del producto
The Model 232HESP is designed to help protect against lightning strikes, power surges, and other types of voltage disturbances. Five RS-232 signals on terminal blocks are supported with a clamping voltage of approximately 15 volts. The 232HESP offers three stages of protection starting with a gas discharge tube followed by a series resistor and finally a Transient Voltage Suppresser (TVS). In order for a surge protector to work properly it is important to have a good connection to earth ground. The 232HESP offers two terminal posts and two metal mounting brackets that provide a good ground connection for the user. The 232HESP has been tested to two specifications at 6 kilovolts, IEC 1000-4-5: 1995 "Surge Immunity Test" and IEEE C62.41-1991 "IEEE Recommended Practice on Surge Voltages in Low-Voltage AC Power Circuits". To ensure the best protection of your equipment some simple connection guidelines should be followed.
- Terminal Block receptacles protects your devices from electric power surges and spikes
- Helps you ensure that your components perform at peak levels
Especificaciones técnicas
| Miscellaneous | |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Technical Information | |
| Protection Type | Lightning |
| Surge | |
| Receptacles | Terminal Block |
| Physical Characteristics | |
| Weight (Approximate) | 6.70 oz (189.94 g) |
| Height | 1.80" (45.72 mm) |
| Width | 3.30" (83.82 mm) |
| Depth | 4.50" (114.30 mm) |
| General Information | |
| Product Type | Surge Suppressor/Protector |
| Manufacturer Part Number | 232HESP |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | 232HESP |
| Product Name | RS-232 High Energy Surge Protector |
| Brand Name | B+B SmartWorx |
