The WilsonPro 1050 passive distributed antenna system is the first FCC and carrier-approved "in-line" booster solution, providing reliable cell coverage deep inside hard-to-reach areas of buildings, such as equipment rooms, and lower floors of highrise buildings. The system consists of two units: a main amplifier and an inline amplifier, located up to 300' from the main booster. The inline booster compensates for signal loss up to 300' of Wilson400 cable.
The WilsonPro 1050 system amplifies weak cell signals to provide reliable voice and data coverage-including 4G to inside spaces where signals may not penetrate. With new eXtended Dynamic Range (XDR) technology, the amplifier never shuts off due to a strong outside signal or changes in outside signals.
Like all WilsonPro cellular signal boosters, the WilsonPro 1050 features cell site protections that auto-detect and prevent any cell tower interference.
The WilsonPro 1050 system amplifies weak cell signals to provide reliable voice and data coverage-including 4G to inside spaces where signals may not penetrate. With new eXtended Dynamic Range (XDR) technology, the amplifier never shuts off due to a strong outside signal or changes in outside signals.
Like all WilsonPro cellular signal boosters, the WilsonPro 1050 features cell site protections that auto-detect and prevent any cell tower interference.
- Industry's first FCC & carrier approved "inline" cellular booster system
- Consists of "main" booster and "inline" booster
- "Inline" booster installed deep inside building and compensates for signal loss in long cable runs to inside antennas
- XDR technology: never shuts down due to overload, even with very strong outside cellular signals
- Automatically compensates for signal loss in up to 300' of cable
- Compatible with all North America cellular networks
- Three year warranty
- Up to +15 dBm downlink power at indoor antenna port, for maximum indoor coverage area
Especificaciones técnicas
| Interfaces/Ports | |
| RF Connector Type | N-Type |
| Miscellaneous | |
| Application/Usage | Building |
| Certifications & Standards | FCC |
| Physical Characteristics | |
| Height | 11.50" (292.10 mm) |
| Width | 18" (457.20 mm) |
| Depth | 3.75" (95.25 mm) |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| General Information | |
| Product Type | Cellular Phone Signal Booster |
| Manufacturer Part Number | 460230F |
| Manufacturer Website Address | http://www.wilsonelectronics.com |
| Manufacturer | Wilson Electronics |
| Product Model | 460230F |
| Product Name | Pro 1050 460230F Cellular Phone Signal Booster |
| Brand Name | WilsonPro |
| Technical Information | |
| Impedance | 50 Ohm |
| Frequency Range | 2110 MHz to 2155 MHz |
| 698 MHz to 716 MHz | |
| 824 MHz to 894 MHz | |
| 1710 MHz to 1755 MHz | |
| 777 MHz to 787 MHz | |
| 746 MHz to 756 MHz | |
| 729 MHz to 746 MHz | |
| 1850 MHz to 1995 MHz | |
| Antenna Type | Yagi |
| Dome | |
| Directional Antenna | |
| Maximum Gain | 70 dB |
| Cellular Data Connectivity Technology | LTE |
| Cellular Generation | 4G |
| Cellular Network Supported | LTE |
| Maximum Coverage Area | 3251.6 m² |
