Acerca del producto
The 4POSTRAILKITWM wall-mount rack shelf kit provides extra support for heavy UPS systems, PDUs or other rack-mount components that weigh 150 pounds or less. It includes two adjustable mounting rails that attach to the mounting rails of your EIA-standard 19-inch wall-mount enclosure. Constructed using cold-rolled steel with a durable powder-coated finish, this heavy-duty rack rail kit comes with mounting hardware compatible with square-hole racks.
The rails offer front-to-rear support for equipment with 17.5-inch-wide rectangular chassis. They also adjust to any setting between 14.5 and 23.5 inches and leave the rack's front and rear mounting holes free to attach equipment. Setup is hassle-free and saves money and time on installation. Threaded-hole rack installation is also supported with user-supplied mounting hardware.
The rails offer front-to-rear support for equipment with 17.5-inch-wide rectangular chassis. They also adjust to any setting between 14.5 and 23.5 inches and leave the rack's front and rear mounting holes free to attach equipment. Setup is hassle-free and saves money and time on installation. Threaded-hole rack installation is also supported with user-supplied mounting hardware.
Features
Additional Rack-Mount Shelf for Your Wall-Mount Rack
- 1U rack rail kit with maximum load capacity of 150 lb.
- Compatible with 19 in. wall-mount open frame racks and enclosures
- Expandable support rails offer front-to-rear support for equipment with 17.5 in. rectangular chassis
- Rails adjust to any setting between 14.5 and 23.5 in.
- Leaves front and rear mounting holes free for equipment
Heavy-Duty Construction with Versatile Mounting Options
- Cold-rolled steel construction with powder-coated finish designed for long life
- Mounting hardware included for quick installation in square-hole rack
- Threaded-hole rack installation supported with user-supplied hardware
Especificaciones técnicas
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Product Information | |
| Device Supported | UPS |
| PDU | |
| Electronic Equipment | |
| Maximum Load Capacity | 150 lb (68038.86 g) |
| Physical Characteristics | |
| Weight (Approximate) | 2.60 lb (1179.34 g) |
| Height | 1.72" (43.69 mm) |
| Width | 1.49" (37.85 mm) |
| Depth | 23.50" (596.90 mm) |
| Product Color | Silver |
| Color Family | Silver |
| General Information | |
| Product Type | Rack Mount |
| Manufacturer Part Number | 4POSTRAILKITWM |
| Manufacturer Website Address | https://tripplite.eaton.com/ |
| Manufacturer | Eaton Corporation |
| Product Model | 4POSTRAILKITWM |
| Product Name | 4-Post 1U Universal Adjustable Rack-Mount Shelf Kit for Wall-Mount Racks |
| Brand Name | Tripp Lite by Eaton |
