The ACX5000 line of Universal Metro Routers adds operational intelligence to metro environments, giving you the option to deploy packet optical, Metro Ethernet, and IP/MPLS infrastructure. The ACX5000 platforms address multiple service provider use cases, including cable distributed access architectures, residential fiber, and mobile backhaul, as well as enterprise applications for utilities, oil and gas, mining, transportation, defense, and public safety industries.
ACX5000 Line Product Family
Juniper Networks ACX Series Universal Metro Routers offer a wide range of metro solutions, including the ACX500, ACX1000, ACX2000, ACX4000, ACX5000, and ACX6000 lines. The ACX5000 line includes five models.
ACX5048: The ACX5048 provides full duplex throughput of 1.44 Tbps in a 1 U platform. Built to handle 1GbE/10GbE capacity and density, it supports 48 1GbE/10GbE and six 40GbE interfaces, making it ideal for Metro Ethernet access and aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5096: The ACX5096 provides full duplex throughput of 2.56 Tbps in a 2 U platform. It supports 48 x 1GbE, 96 x 10GbE, and 8 x 40GbE interfaces, making it ideal for metro aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5448: The ACX5448 offers 48 1GbE/10GbE aggregation ports, four high-capacity 40GbE/100GbE uplink ports, and full Metro Ethernet and IP/ MPLS VPN services in a space- and cost-optimized platform, smoothing the transition from 10GbE to 100GbE for service providers preparing for the emerging 5G rollout.
ACX5448-D: The ACX5448-D supports 36 1GbE/10GbE, two 100GbE, and two 100G/200G dense wavelength-division multiplexing (DWDM) ports using CFP2-DCO. It is designed for packet-optical convergence to reduce TCO and to help service providers prepare for the emerging 5G rollout.
ACX5448-M: The ACX5448-M supports 44 1GbE/10GbE and six 100GbE ports, as well as advanced security capabilities such as Media Access Control Security (MACsec) on all 1GbE/10GbE ports.
ACX5000 Line Product Family
Juniper Networks ACX Series Universal Metro Routers offer a wide range of metro solutions, including the ACX500, ACX1000, ACX2000, ACX4000, ACX5000, and ACX6000 lines. The ACX5000 line includes five models.
ACX5048: The ACX5048 provides full duplex throughput of 1.44 Tbps in a 1 U platform. Built to handle 1GbE/10GbE capacity and density, it supports 48 1GbE/10GbE and six 40GbE interfaces, making it ideal for Metro Ethernet access and aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5096: The ACX5096 provides full duplex throughput of 2.56 Tbps in a 2 U platform. It supports 48 x 1GbE, 96 x 10GbE, and 8 x 40GbE interfaces, making it ideal for metro aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5448: The ACX5448 offers 48 1GbE/10GbE aggregation ports, four high-capacity 40GbE/100GbE uplink ports, and full Metro Ethernet and IP/ MPLS VPN services in a space- and cost-optimized platform, smoothing the transition from 10GbE to 100GbE for service providers preparing for the emerging 5G rollout.
ACX5448-D: The ACX5448-D supports 36 1GbE/10GbE, two 100GbE, and two 100G/200G dense wavelength-division multiplexing (DWDM) ports using CFP2-DCO. It is designed for packet-optical convergence to reduce TCO and to help service providers prepare for the emerging 5G rollout.
ACX5448-M: The ACX5448-M supports 44 1GbE/10GbE and six 100GbE ports, as well as advanced security capabilities such as Media Access Control Security (MACsec) on all 1GbE/10GbE ports.
- 100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network connectivity
- With 100GBase-X technology, enjoy up to 100Gbps data transfer rate over supported network cable
Especificaciones técnicas
| I/O Expansions | |
| Total Number of Expansion Slots | 52 |
| Power Description | |
| Power Source | DC |
| Redundant Power Supply Supported | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 22.45 lb (10183.15 g) |
| Height | 1.70" (43.18 mm) |
| Width | 17.26" (438.40 mm) |
| Depth | 21.81" (553.97 mm) |
| General Information | |
| Product Type | Router |
| Manufacturer Part Number | ACX5448-M-DC-AFO |
| Manufacturer Website Address | http://www.juniper.net |
| Manufacturer | Juniper Networks, Inc |
| Product Model | ACX5448 |
| Product Name | ACX5448 Router |
| Product Series | ACX |
| Brand Name | Juniper |
| Network & Communication | |
| Network Technology | 100GBase-X |
| 10GBase-X | |
| Ethernet Technology | 100 Gigabit Ethernet |
| Networking Standards | IEEE 802.3ae |
| IEEE 802.3ad | |
| IEEE 802.3 | |
| IEEE 802.1x | |
| IEEE 802.1Q | |
| IEEE 802.1p |
