The Dell Smart-UPS Online DLRT5KRMXLT provides instant battery power to your critical electronic devices, keeping you and your business productive even during power outages. It delivers high-density, true double-conversion online power protection for servers, voice/data networks, medical labs, and light industrial applications. All 4 outlets provide battery backup power and safeguard your expensive electronics from potentially harmful power conditions such as spikes and surges.
- Provides instant, clean power to your critical electronic devices during a power outage
- Four battery and surge protected outlets ensure all of your critical electronics will be backed-up and protected
- Two switched outlet groups allow you to reboot hung equipment, automatically shed less critical equipment, and sequence both the startup and shutdown of attached equipment
- The pure sine wave output while online or on battery provides the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics
- Green Mode bypasses unused electrical components to achieve high operating efficiency without sacrificing power protection
- Intuitive LCD panel provides Smart-UPS and power status at a glance
- Prevent critical data loss by staying powered during a blackout with up to 4.80 kW load capacity
- 5000 kVA load capacity provides sufficient backup during power failures
- Up to 4.40 minute runtime on full load to preserve critical data from power shortage interruptions
Especificaciones técnicas
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | SNMP/Telnet/HTTP/RS-232 |
| SmartSlot | |
| SNMP/Modbus | |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Half Load) | 12.60 Minute |
| Backup/Run Time (Full Load) | 4.40 Minute |
| Battery Characteristics | Maintenance-free, Sealed, Leak-proof |
| Miscellaneous | |
| Package Contents |
|
| Software Included | APC PowerChute |
| Certifications & Standards |
|
| Energy Star | Yes |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| Expansion Slot Detail | 1 (total) / 1 (free) x SmartSlot |
| Physical Characteristics | |
| Weight (Approximate) | 120.15 lb (54500 g) |
| Form Factor | Rack/Tower |
| Rack Height | 3U |
| Height | 5.12" (130 mm) |
| Width | 17.01" (432 mm) |
| Depth | 28.31" (719 mm) |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | A8572199 |
| Manufacturer Website Address | http://www1.ca.dell.com |
| Manufacturer | Dell Technologies |
| Product Name | Smart-UPS On-Line 5000VA Rack/Tower UPS |
| Product Line | Smart-UPS On-Line |
| Brand Name | Dell |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Output Voltage | 208 V AC |
| 240 V AC | |
| Waveform Type | Sine Wave |
| Input Voltage Range | 100 V AC - 275 V AC |
| Output Frequency | 60 Hz |
| 50 Hz | |
| Input Frequency | 70 Hz |
| 40 Hz | |
| Load Capacity (VA) | 5000 kVA |
| Load Capacity (Watt) | 4.80 kW |
| Technical Information | |
| Application/Usage | Mission Critical Equipment |
| Server | |
| Voice/Data Network | |
| Medical Laboratory | |
| Light Industrial Application | |
| Electronic Equipment | |
| Electronic Device | |
| Business | |
| Features | Audible Alarm |
| Battery Management System (BMS) | |
| Surge Suppression | Yes |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-30R |
| NEMA L6-20R | |
| Number of Battery & Surge Outlets | 4 |
| Receptacle Detail | 2 x NEMA L6-20R |
| 2 x NEMA L6-30R |
