Acerca del producto
5ch Dashcam 4G/GPS Features:
- Up to 1080P resolution, with 108° FOV
- Supports GPS and speed overlay on picture
- Built-in Wi-Fi module, supports Wi-Fi AP
- Supports 4G network
- Supports dual-TF card storage and recording overwrite
- Supports preview, playback and editing parameters via APP
- Supports connecting to HCP&HCC for uploading and playback
- Adopts build-in Gyroscope
- Compatible with 4-ch TVI Camera
- Supports object detection, driving safety monitoring etc.
- Easy installation and operation
- Low power consumption and high performance
5ch Dashcam 4G/GPS Specifications:
- Camera
- Image Sensor1/2.5'' Progressive Scan CMOS
- Min. Illumination0.01 Lux @ (AGC ON)
- Shutter Speed1/3 s to 1/100, 000 s
- Lens
- Focal LengthFixed focal lens, 3.35mm
- FOV
- Horizontal FOV: 108°
- Vertical FOV: 56°
- Diagonal FOV: 135°
- Lens MountM12
- Max. ApertureF2.0
- Video
- Video Input5-channel video (default: 1 channel; extension: 4 channels)
- Main Stream
- CH1:
- 25fps 1080P 1920 × 1080 (default)
- 25fps 720P 1280 × 720
- CH2~CH5:
- 25fps 720P 1280 × 720 (default)
- Sub-Stream
- CH1:
- 25fps 720P 1280×720
- 25fps 480P 640×480 (default)
- CH2~CH5:
- 25fps 480P 640×480 (default)
- Video Compression
- H.264 (default)
- H.265
- Audio
- Audio Input1-channel audio
- Audio Compression
- G711U (Default)
- G711A
- AAC
- Built-In MicOmnidirectional pickup, frequency response 100-20000 Hz
- Built-In SpeakerMax 0.8 W, with adjustable volume, not less than 50 dB at 1 m distance
- Wi-Fi
- Wi-Fi ProtocolIEEE 802.11b/g/n
- Frequency Range2.4 GHz
- Mobile Communication
- SIM Card Slot1, Industry Micro SIM, Plug-in type
- Dial-Up
- Baseline:
- FDD-LTE: B1, B3, B5, B8
- TDD-LTE: B38, B39, B40, B41
- TD-SCDMA: B34, B39
- UMTS: B1, B8
- EV-DO: BC0
- CDMA 1x: BC0
- GSM/GPRS/EDGE: 900/1800 MHz
- Australia
- FDD-LTE: B1, B3, B5, B7, B28
- TDD-LTE: B40
- UMTS: B1, B5
- Europe
- FDD-LTE: B1, B3, B5, B7, B8, B20
- TDD-LTE: B40
- UMTS: B1, B8
- GSM/GPRS/EDGE: 900/1800 MHz
- Latin America
- FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B10, B28, B66
- TDD-LTE: B38, B40, B41
- UMTS: B1, B2, B4, B5, B8
- GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Warning: The industrial SIM card (MP2) is required, and the ordinary SIM card (MP1) is prohibited. We are not responsible for any problem caused by the use of any ordinary SIM card.
- Image
- SNR40 dB
- Wide Dynamic Range (WDR)Supports Digital WDR
- Image SettingsAdjustable brightness, chroma, contrast, color saturation, and sharpness
- OSDDate, Time, GPS, Speed, etc.
- Interface
- USB Interface1, Mini USB 2.0, used for connecting to peripheral device
- Reset Key1, Pinhole button
- Alarm Input2
- RS-2321
- Satellite Positioning
- GPS Information Detection
- BDS (BeiDou Navigation Satellite System)
- GPS (Global Positioning System)
- GPS Information Detection
- Indicator
- Wi-Fi Status Indicator
- Off: Wi-Fi AP closed
- Low Frequency Flashing blue: Wi-Fi AP open but no APP connection
- High Frequency Flashing blue: Wi-Fi AP open and APP connection normal
- Network Status Indicator (4G)
- Off: No 4G signal
- Steady white: 4G signal and the platform connection normal
- Flashing white: 4G signal normal but no platform connection
- Recording Status Indicator(REC)
- Off: The built-in or extended camera stops / fails
- Steady white: The built-in or extended camera is recording normally
- General
- SystemEmbedded Linux
- Language: Currently only supports English
*The language includes APP interface language and voice reminder.
- Product Dimension124.0 mm × 82.0 mm × 33.0 mm (4.9"" × 3.2"" × 1.3"")
- Product WeightApprox. 300 g (0.7 lb.)
- Image FormatJPEG
- Power Supply9 to16V , support 12/24V with the buck line
- Package Dimension223 mm×153 mm×63 mm (8.8""×6.0""×2.5"")
- Operating Temperature-20°C to 45°C (-4°F to 113°F)
- Protection
- IP4X (*The dash camera is non-waterproof)
- With Package WeightApprox. 600 g (1.3 lb.)
- Power Interface1, 8-pin BM Male Terminal
- Sensor
Six-axis G-Sensor
*Harsh acceleration, Harsh deceleration and Harsh cornering
- Operating Humidity10% to 95% (non-condensing)
Especificaciones técnicas
5ch Dashcam 4G/GPS Features:
- Up to 1080P resolution, with 108° FOV
- Supports GPS and speed overlay on picture
- Built-in Wi-Fi module, supports Wi-Fi AP
- Supports 4G network
- Supports dual-TF card storage and recording overwrite
- Supports preview, playback and editing parameters via APP
- Supports connecting to HCP&HCC for uploading and playback
- Adopts build-in Gyroscope
- Compatible with 4-ch TVI Camera
- Supports object detection, driving safety monitoring etc.
- Easy installation and operation
- Low power consumption and high performance
5ch Dashcam 4G/GPS Specifications:
- Camera
- Image Sensor1/2.5'' Progressive Scan CMOS
- Min. Illumination0.01 Lux @ (AGC ON)
- Shutter Speed1/3 s to 1/100, 000 s
- Lens
- Focal LengthFixed focal lens, 3.35mm
- FOV
- Horizontal FOV: 108°
- Vertical FOV: 56°
- Diagonal FOV: 135°
- Lens MountM12
- Max. ApertureF2.0
- Video
- Video Input5-channel video (default: 1 channel; extension: 4 channels)
- Main Stream
- CH1:
- 25fps 1080P 1920 × 1080 (default)
- 25fps 720P 1280 × 720
- CH2~CH5:
- 25fps 720P 1280 × 720 (default)
- Sub-Stream
- CH1:
- 25fps 720P 1280×720
- 25fps 480P 640×480 (default)
- CH2~CH5:
- 25fps 480P 640×480 (default)
- Video Compression
- H.264 (default)
- H.265
- Audio
- Audio Input1-channel audio
- Audio Compression
- G711U (Default)
- G711A
- AAC
- Built-In MicOmnidirectional pickup, frequency response 100-20000 Hz
- Built-In SpeakerMax 0.8 W, with adjustable volume, not less than 50 dB at 1 m distance
- Wi-Fi
- Wi-Fi ProtocolIEEE 802.11b/g/n
- Frequency Range2.4 GHz
- Mobile Communication
- SIM Card Slot1, Industry Micro SIM, Plug-in type
- Dial-Up
- Baseline:
- FDD-LTE: B1, B3, B5, B8
- TDD-LTE: B38, B39, B40, B41
- TD-SCDMA: B34, B39
- UMTS: B1, B8
- EV-DO: BC0
- CDMA 1x: BC0
- GSM/GPRS/EDGE: 900/1800 MHz
- Australia
- FDD-LTE: B1, B3, B5, B7, B28
- TDD-LTE: B40
- UMTS: B1, B5
- Europe
- FDD-LTE: B1, B3, B5, B7, B8, B20
- TDD-LTE: B40
- UMTS: B1, B8
- GSM/GPRS/EDGE: 900/1800 MHz
- Latin America
- FDD-LTE: B1, B2, B3, B4, B5, B7, B8, B10, B28, B66
- TDD-LTE: B38, B40, B41
- UMTS: B1, B2, B4, B5, B8
- GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Warning: The industrial SIM card (MP2) is required, and the ordinary SIM card (MP1) is prohibited. We are not responsible for any problem caused by the use of any ordinary SIM card.
- Image
- SNR40 dB
- Wide Dynamic Range (WDR)Supports Digital WDR
- Image SettingsAdjustable brightness, chroma, contrast, color saturation, and sharpness
- OSDDate, Time, GPS, Speed, etc.
- Interface
- USB Interface1, Mini USB 2.0, used for connecting to peripheral device
- Reset Key1, Pinhole button
- Alarm Input2
- RS-2321
- Satellite Positioning
- GPS Information Detection
- BDS (BeiDou Navigation Satellite System)
- GPS (Global Positioning System)
- GPS Information Detection
- Indicator
- Wi-Fi Status Indicator
- Off: Wi-Fi AP closed
- Low Frequency Flashing blue: Wi-Fi AP open but no APP connection
- High Frequency Flashing blue: Wi-Fi AP open and APP connection normal
- Network Status Indicator (4G)
- Off: No 4G signal
- Steady white: 4G signal and the platform connection normal
- Flashing white: 4G signal normal but no platform connection
- Recording Status Indicator(REC)
- Off: The built-in or extended camera stops / fails
- Steady white: The built-in or extended camera is recording normally
- General
- SystemEmbedded Linux
- Language: Currently only supports English
*The language includes APP interface language and voice reminder.
- Product Dimension124.0 mm × 82.0 mm × 33.0 mm (4.9"" × 3.2"" × 1.3"")
- Product WeightApprox. 300 g (0.7 lb.)
- Image FormatJPEG
- Power Supply9 to16V , support 12/24V with the buck line
- Package Dimension223 mm×153 mm×63 mm (8.8""×6.0""×2.5"")
- Operating Temperature-20°C to 45°C (-4°F to 113°F)
- Protection
- IP4X (*The dash camera is non-waterproof)
- With Package WeightApprox. 600 g (1.3 lb.)
- Power Interface1, 8-pin BM Male Terminal
- Sensor
Six-axis G-Sensor
*Harsh acceleration, Harsh deceleration and Harsh cornering
- Operating Humidity10% to 95% (non-condensing)
