Camden Electric Strike with Round Faceplate Overview
CX-ED1309 Electric Strike Body may be purchased with a separate ANSI square, ANSI round, hollow metal, or wood door faceplate, with either a brushed aluminum or dark bronze finish.
CX-ED1379 packages the Strike Body with (2) ANSI round faceplates; one with a brushed aluminum finish and one with a dark bronze finish.
Camden Electric Strike with Round Faceplate Features
- Ideal for cylindrical or spring latch locksets in wood, hollow metal, or aluminum frames
- CX-ED1379 includes two ANSI round faceplates
- Selectable Fail Safe/Fail Secure
- Selectable 12/24V, AC/DC
- 1/2” to 5/8” Latch Projection
- Easy Fit Connectors and Mounting Tabs Included
- A wide selection of aluminum and dark bronze faceplates
- 5 Year Warranty
Camden Electric Strike with Round Faceplate Specifications
- Voltage: 12/24V AC/DC
- Current Draw:
- 260mA @ 12V DC
- 150mA @ 24V DC
- Faceplates:
- CX-ED1379:
- Brushed Aluminum (BHMA 628)
- Dark Bronze (BHMA 710)
- CX-ED1379:
- Static Strength: 1,500 Lbs.
- Dynamic Strength: 70 Ft-Lbs.
- Endurance: 1,000,000 Cycles (Factory Test), 250,000 Cycles (UL Verified)
- Operation: AC-Buzz, DC-Silent
- Duty: Continuous
- Dimensions: Body: 4 7/8"" H x 1 11/16"" W x 1 5/8"" D (124mm x 43mm x 42mm)
