Introduction
The Advantech IDS-3215 Embedded Industrial Panel Mount Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series with standard integrated frame design, supports rear and VESA mounting which brings the benefits of easy installation and provides flexibility for different applications.- Projective Capacitive touchscreen technology offers two essential advantages, not only can you touch the panel with your bare finger, but you can also actuate it with surgical gloves or slender cotton gloves on
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- View your content easily in well-lit areas with 500 cd/m² brightness
- VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
Especificaciones técnicas
| Touchscreen Information | |
| Touchscreen Type | Projected Capacitive |
| Interfaces/Ports | |
| USB | Yes |
| DVI | Yes |
| VGA | Yes |
| Number of USB Ports | 1 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Video | |
| Brightness | 500 cd/m² |
| Color Supported | 16.7 Million Colors |
| Maximum Resolution | 1024 x 768 |
| Native Contrast Ratio | 2,500:1 |
| Physical Characteristics | |
| Weight (Approximate) | 9.92 lb (4500 g) |
| Height | 11.46" (291 mm) |
| Width | 14.37" (365 mm) |
| Depth | 1.50" (38 mm) |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| General Information | |
| Product Type | LCD Touchscreen Monitor |
| Manufacturer Part Number | IDS-3215P-50XGA1 |
| Manufacturer Website Address | http://www.advantech.com |
| Packaged Quantity | 1 |
| Manufacturer | Advantech Co., Ltd |
| Product Model | IDS-3215P |
| Product Name | IDS-3215 15" XGA Industrial Panel Mount Monitor |
| Product Series | IDS-3215 |
| Brand Name | Advantech |
| Technical Information | |
| Response Time | 16 ms |
| Features | Anti-reflective |
| Mount Type | Panel Mount |
| Rear Mount | |
| Viewable Screen Size | 15" |
| Screen Mode | XGA |
| Horizontal Viewing Angle | 176° |
| Vertical Viewing Angle | 176° |
| Backlight Technology | LED |
| Screen Size Class | 15" |
