Acerca del producto
The Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera provides high definition output. It supports H.265+ video compression, which assures savings in bandwidth and storage.
The camera is capable of providing a 360° panoramic image of the surveillance environment and supports up to 18 live view display modes. These are designed for three mount types and two decoding modes, and provide a wide range of panoramic display options.
The Fisheye camera is equipped with a 6 MP lens, and has an IR range of up to 50 ft (15 m).
Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera Features:
- 1/1.8"" (6 MP) Progressive Scan CMOS
- 3072 x 2048 Resolution @ 30 fps
- Up to 50 ft (15 m) IR Range
- 360° Viewing Angle
- Multiple Viewing Modes
- Multiple ePTZ Streams with Preset and Patrol
- Ceiling, Wall, or Table Mount Modes
- Alarm and Audio Inputs and Outputs
- IP67 and IK10 Protection (-V Models Only)
- 12 VDC and PoE (802.3af), 12 W
- Built-in Heater
Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera Specifications:
- Camera:
- Image Sensor:1/1.8"" progressive scan CMOS
- Minimum Illumination: Color: 0.047 lux @ (f/2.6, AGC on), B/W: 0.0047 lux @ (f/2.6, AGC on), 0 lux with IR
- Shutter Speed: 1 to 1/100,000 s
- Slow Shutter: Supported
- Lens: 1.27 mm, f/2.6; horizontal field of view: 180° (wall mount), 360° (ceiling mount), 360° (table mount)
- Lens Mount: M12
- Day/Night: IR cut filter
- Digital Noise Reduction: 3D DNR
- WDR: Digital WDR
- Compression Standard:
- Video Compression: Main stream: H.265+/H.265/H.264+/H.264; sub stream: H.265/H.264/MJPEG
- H.264 Type: Baseline profile/main profile/high profile
- H.264+: Main stream supported
- H.265 Type: Main profile
- H.265+: Main stream supported
- Video Bit Rate: 32 Kbps to 16 Mbps
- SVC: H.265 and H.264 supported
- IR
- IR Range: Up to 50 ft (15 m) with 3 LEDs. Each LED is controlled independently.
- Wavelength: 850 nm
- Image:
- Maximum Resolution: 3072 x 2048
- Main Stream: 30 fps (3072 × 2048, 2048 × 2048, 1280 × 1280)
- Sub Stream: 30 fps (720 × 720, 720 × 480)
- Image Enhancement: BLC, HLC, defog, 3D DNR
- Image Setting: Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software or web browser
- Day/Night Switching: Day/night/auto/schedule/triggered by alarm in
- Picture Overlay: Logo picture can be overlaid on video with 128 x 128 24-bit bmp format
- Live View Display:
- Mount Type: Table, wall and ceiling mounts
- Decoding Mode: Hardware and software decoding
- Display Mode: Total of 18 display modes supported: Software decoding: Ceiling Mount: Fisheye View, 180° Panorama View, 360° Panorama View, 360° Panorama + PTZ, 360° Panorama + 3 PTZ, 360° Panorama + 6 PTZ, 360° Panorama + 8 PTZ, 2 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye +8 PTZ, Hemisphere, AR Hemisphere, Cylinder Wall Mount: Fisheye View, Panorama View, Panorama + 3 PTZ, Panorama + 8 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye + 8 PTZ Table Mount: Fisheye View, 180° Panorama View, 360° Panorama View, 360° Panorama + PTZ, 360° Panorama + 3 PTZ, 360° Panorama + 6 PTZ, 360° Panorama + 8 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye + 8 PTZ, Cylinder Hardware Decoding: Ceiling Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion Wall Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion Table Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion
- Audio:
- Environment Noise Filtering: Supported
- Audio Sampling Rate: 8 kHz/16 kHz
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)
- Smart Features:
- Behavior Analysis: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detaction
- Exception Detection: Audio exception detection
- Region of Interest: Four fixed regions for main stream and sub-stream
- Network:
- Network Storage: Supports MicroSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
- Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login, HDD full, HDD error
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- Security Measures: Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
- General Function: One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Standard: ONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live View: Up to 20 channels
- User/Host: Up to 32 users. 3 user levels, administrator, operator and user
- Client: iVMS-4200, Hik-Connect
- Web Browser: IE 8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
- Interface:
- Communication Interface: One RJ-45 10M/100M/1000M self-adaptive Ethernet port
- Audio: One audio input (line in, 3.5 mm), one audio output (line out, 3.5 mm); two built-in microphones, one built-in speaker, mono sound
- Alarm: 1-ch alarm input, maximum 12 V; 1-ch alarm output, maximum 24 VDC, 1 A
- On-Board Storage: Built-in microSD/SDHC/SDXC slot, up to 256 GB
- Reset Button: Yes
- General:
- Operating Conditions -40° to 140° F (-40° to 60° C); humidity 95% or less (non-condensing)
- Power Supply: 12 VDC + 20%, PoE (802.3af, class 0), two-core terminal block
- Heater: Built in
- Power Consumption: 12 VDC, 0.9 A, maximum 11 W, PoE (802.3af, 36 to 57 V), 0.3 A to 0.2 A, maximum 12 W
- Protection: ---
- Material: Metal
- Dimensions: 6.6"" x 6"" x 2"" (167.4 mm x 152.8 mm x 50.1 mm)
- Weight: 3.09 lbs (1.40 kg)
Especificaciones técnicas
The Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera provides high definition output. It supports H.265+ video compression, which assures savings in bandwidth and storage.
The camera is capable of providing a 360° panoramic image of the surveillance environment and supports up to 18 live view display modes. These are designed for three mount types and two decoding modes, and provide a wide range of panoramic display options.
The Fisheye camera is equipped with a 6 MP lens, and has an IR range of up to 50 ft (15 m).
Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera Features:
- 1/1.8"" (6 MP) Progressive Scan CMOS
- 3072 x 2048 Resolution @ 30 fps
- Up to 50 ft (15 m) IR Range
- 360° Viewing Angle
- Multiple Viewing Modes
- Multiple ePTZ Streams with Preset and Patrol
- Ceiling, Wall, or Table Mount Modes
- Alarm and Audio Inputs and Outputs
- IP67 and IK10 Protection (-V Models Only)
- 12 VDC and PoE (802.3af), 12 W
- Built-in Heater
Hikvision DS-2CD6365G0E-I(V)S Network Fisheye Camera Specifications:
- Camera:
- Image Sensor:1/1.8"" progressive scan CMOS
- Minimum Illumination: Color: 0.047 lux @ (f/2.6, AGC on), B/W: 0.0047 lux @ (f/2.6, AGC on), 0 lux with IR
- Shutter Speed: 1 to 1/100,000 s
- Slow Shutter: Supported
- Lens: 1.27 mm, f/2.6; horizontal field of view: 180° (wall mount), 360° (ceiling mount), 360° (table mount)
- Lens Mount: M12
- Day/Night: IR cut filter
- Digital Noise Reduction: 3D DNR
- WDR: Digital WDR
- Compression Standard:
- Video Compression: Main stream: H.265+/H.265/H.264+/H.264; sub stream: H.265/H.264/MJPEG
- H.264 Type: Baseline profile/main profile/high profile
- H.264+: Main stream supported
- H.265 Type: Main profile
- H.265+: Main stream supported
- Video Bit Rate: 32 Kbps to 16 Mbps
- SVC: H.265 and H.264 supported
- IR
- IR Range: Up to 50 ft (15 m) with 3 LEDs. Each LED is controlled independently.
- Wavelength: 850 nm
- Image:
- Maximum Resolution: 3072 x 2048
- Main Stream: 30 fps (3072 × 2048, 2048 × 2048, 1280 × 1280)
- Sub Stream: 30 fps (720 × 720, 720 × 480)
- Image Enhancement: BLC, HLC, defog, 3D DNR
- Image Setting: Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software or web browser
- Day/Night Switching: Day/night/auto/schedule/triggered by alarm in
- Picture Overlay: Logo picture can be overlaid on video with 128 x 128 24-bit bmp format
- Live View Display:
- Mount Type: Table, wall and ceiling mounts
- Decoding Mode: Hardware and software decoding
- Display Mode: Total of 18 display modes supported: Software decoding: Ceiling Mount: Fisheye View, 180° Panorama View, 360° Panorama View, 360° Panorama + PTZ, 360° Panorama + 3 PTZ, 360° Panorama + 6 PTZ, 360° Panorama + 8 PTZ, 2 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye +8 PTZ, Hemisphere, AR Hemisphere, Cylinder Wall Mount: Fisheye View, Panorama View, Panorama + 3 PTZ, Panorama + 8 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye + 8 PTZ Table Mount: Fisheye View, 180° Panorama View, 360° Panorama View, 360° Panorama + PTZ, 360° Panorama + 3 PTZ, 360° Panorama + 6 PTZ, 360° Panorama + 8 PTZ, 4 PTZ, Fisheye + 3 PTZ, Fisheye + 8 PTZ, Cylinder Hardware Decoding: Ceiling Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion Wall Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion Table Mount: Fisheye View, 180° Panorama View, Panorama View, 4 PTZ, Fisheye + 3 PTZ, 4 PTZ Fusion
- Audio:
- Environment Noise Filtering: Supported
- Audio Sampling Rate: 8 kHz/16 kHz
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)
- Smart Features:
- Behavior Analysis: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detaction
- Exception Detection: Audio exception detection
- Region of Interest: Four fixed regions for main stream and sub-stream
- Network:
- Network Storage: Supports MicroSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
- Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login, HDD full, HDD error
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- Security Measures: Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
- General Function: One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Standard: ONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live View: Up to 20 channels
- User/Host: Up to 32 users. 3 user levels, administrator, operator and user
- Client: iVMS-4200, Hik-Connect
- Web Browser: IE 8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
- Interface:
- Communication Interface: One RJ-45 10M/100M/1000M self-adaptive Ethernet port
- Audio: One audio input (line in, 3.5 mm), one audio output (line out, 3.5 mm); two built-in microphones, one built-in speaker, mono sound
- Alarm: 1-ch alarm input, maximum 12 V; 1-ch alarm output, maximum 24 VDC, 1 A
- On-Board Storage: Built-in microSD/SDHC/SDXC slot, up to 256 GB
- Reset Button: Yes
- General:
- Operating Conditions -40° to 140° F (-40° to 60° C); humidity 95% or less (non-condensing)
- Power Supply: 12 VDC + 20%, PoE (802.3af, class 0), two-core terminal block
- Heater: Built in
- Power Consumption: 12 VDC, 0.9 A, maximum 11 W, PoE (802.3af, 36 to 57 V), 0.3 A to 0.2 A, maximum 12 W
- Protection: ---
- Material: Metal
- Dimensions: 6.6"" x 6"" x 2"" (167.4 mm x 152.8 mm x 50.1 mm)
- Weight: 3.09 lbs (1.40 kg)
