Acerca del producto
Intel® Atom Quad Core/Dual Core ProcessorPalm-size form factor: 170 (L) x 117 (W) x 52.6 mm (H)Supports 2 x LAN, 2 x COM port, 1 x HDMI, 1 x Display Port, 4 x USB3.0, CANBus, and DCIN 12~24VBuilt-in 1 x M
2 expansion slot (i.e.: Wi-Fi module), 1 x Full size Mini PCIe expansion slot (i.e.: mSATA/ 3G/LTE module)Support on-board eMMC and 1 x 2.5 HDD or SDD storage.Wide operating temperature -20 ~ 60 °C supportComplete certification for EMC and Safety
Especificaciones técnicas
| Storage | |
| Flash Memory Capacity | 32 GB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| LAN Model | RTL8111G |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Memory Technology | DDR3L SDRAM |
| Graphics Memory Accessibility | Shared |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Maximum Power Supply Wattage | 36 W |
| Processor | |
| Processor Type | Atom |
| Processor Model | x5-E3930 |
| Processor Manufacturer | Intel |
| Memory | |
| Maximum Memory Supported | 8 GB |
| Standard Memory | 4 GB |
| Memory Technology | DDR3L SDRAM |
| Total Number of Memory Slots | 1 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Form Factor | Box PC |
| Height | 2.07" (52.60 mm) |
| Width | 4.61" (117 mm) |
| Depth | 6.69" (170 mm) |
| General Information | |
| Product Type | Desktop Computer |
| Manufacturer Part Number | EPC-U2117E3W-03Y10 |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | EPC-U2117 |
| Product Name | EPC-U2117 Desktop Computer |
| Product Series | EPC-U |
| Brand Name | Advantech |
