Product Overview
The EX4100-H ruggedized line of Ethernet access switches is tailored for harsh indoor and outdoor environments where extended temperature, potential physical impact, and vibration conditions are common. Use cases include but are not limited to:
- EV charging stations
- Petrol/gas stations
- Industrial automation and manufacturing
- Remote surveillance
- Transportation
As part of the underlying infrastructure for Juniper Mist Wired Assurance, the EX4100-H is purpose-built for and managed by the cloud. Mist AI provides visibility into the experience of connected devices, enabling streamlined operations while delivering an experience-first approach to access layer switching.
Product Description
The Juniper Networks® EX4100-H ruggedized line of Ethernet switches offers a fanless, secure, reliable, cloud-native portfolio delivering high-quality network services in extreme conditions, including freezing and scorching temperatures, with an extended operating temperature range for extreme indoor and outdoor applications. EX4100-H switches are ideal for use cases where extreme temperatures, potential physical impact, and vibrations are common.
EX4100-H switches combine the simplicity of the cloud, the power of Mist AI™, and a robust, high-performance hardware foundation to deliver a differentiated approach to access switching in the cloud, mobile, and IoT era. With Juniper® Mist™Wired Assurance, you can effortlessly onboard, configure, and manage EX4100-H switches from the cloud. This simplifies operations and improves visibility and troubleshooting, ensuring optimal experiences for connected devices.
Key features of the EX4000 line include:
- Cloud-native, AI-Native switches with Wired Assurance and Marvis VNA
- Fanless with an extended operating temperature range of -40°C to +75°C for harsh environments
- Ruggedized, compact form factor for easy installation in tight spaces
- Compliant to IP30 and supports a relative humidity range of 5% to 95%, ensuring non-condensing operation
- Meets many industrial certifications, making it suitable for use in a wide range of applications that need high tolerances for constant vibrations, shocks, and electromagnetic immunity
- Dry contact alarm: two alarms in and one alarm out to signal external sensors
- Dual redundant PSUs: two AC PSUs or two DC PSUs or one AC and one DC PSU
- Ethernet VPN-Virtual Extensible LAN (EVPN-VXLAN) to the access layer
- Standards-based microsegmentation using group-based policies (GBPs)
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Useful for the multi-tenant unit and multi-business unit with Layer 4 traffic classifiers and bandwidth limit
- Managed switch provides a reliable foundation for your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Quickly and easily set up a wired network with 24 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
- Cascade to other network devices through the uplink port to expand your local area network
Especificaciones técnicas
| Physical Characteristics | |
| Form Factor | Compact |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 8 |
| Total Number of Expansion Slots | 8 |
| Management & Protocols | |
| Manageable | Yes |
| Data Link Protocols | HTTPs |
| HTTP | |
| Technical Information | |
| Features | Fanless |
| Hot-swappable | |
| Access Control List | |
| High Availability Supported | Yes |
| AI-powered | Yes |
| Power Description | |
| Power Source | DC |
| Power Supply | |
| Number of Power Supplies Supported | 2 |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| PoE Budget | 370 W |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | EX4100-H-24MP-DC |
| Manufacturer Website Address | http://www.juniper.net |
| Manufacturer | Juniper Networks, Inc |
| Product Model | EX4100-H-24MP-DC |
| Product Name | EX4100-H-24MP-DC Ethernet Switch |
| Product Series | EX4100-H |
| Brand Name | Juniper |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 8 x 2.5 Gigabit Ethernet PoE++ |
| 4 x 10 Gigabit Ethernet Uplink | |
| 4 x 10 Gigabit Ethernet Expansion Slot | |
| 16 x Gigabit Ethernet PoE++ | |
| Media & Performance | |
| Network Technology | 2.5GBase-T |
| 10GBase-X | |
| 1000Base-T | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Gigabit Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Miscellaneous | |
| Application/Usage | Business |
| Outdoor | |
| Data Center | |
| Network | |
| Indoor | |
| Enterprise | |
| Campus | |
| Certifications & Standards | Electromagnetic Compatibility (EMC) Requirements
|
| Network & Communication | |
| Layer Supported | 4 |
| Networking Standards | IEEE 802.3x |
| IEEE 802.3z | |
| IEEE 802.3u | |
| IEEE 802.1D | |
| IEEE 802.1ak | |
| IEEE 802.1ae | |
| IEEE 802.1ab | |
| IEEE 802.3bz | |
| IEEE 802.3bt | |
| IEEE 802.3at | |
| IEEE 802.3ah | |
| IEEE 802.3af | |
| IEEE 802.3ae | |
| IEEE 802.3ab | |
| IEEE 802.3 | |
| IEEE 802.1x | |
| IEEE 802.1s | |
| IEEE 802.1Q | |
| IEEE 802.1p | |
| IEEE 802.3by |
