Acerca del producto
Cisco Compute Hyperconverged with Nutanix is a hyperconverged infrastructure solution integrating Cisco's best-in-class compute (Cisco Unified Computing System), datacenter networking, and SaaS infrastructure management platform (Cisco Intersight) with Nutanix's market-leading hyperconverged storage software, Nutanix Cloud Platform.
The Cisco Compute Hyperconverged with Nutanix family of appliances delivers pre-configured UCS servers that are ready to be deployed as nodes to form Nutanix clusters in a variety of configurations. Each server appliance contains three software layers: UCS server firmware, hypervisor (Nutanix AHV), and hyperconverged storage software (Nutanix AOS).
Physically, nodes are deployed into clusters, with a cluster consisting of Cisco Compute Hyperconverged All-NVMe/All-Flash Servers. Clusters support a variety of workloads like virtual desktops, general-purpose server virtual machines in edge, data center and mission-critical high-performance environments.
The Cisco Compute Hyperconverged HCIAF220C M7 All-NVMe/All-Flash Servers harnesses the power of the latest Intel® Xeon® Scalable Processors and offers the following:
CPU:
- Up to 2x 5th Generation Intel® Xeon® Scalable Processors with up to 60 cores per processor or
- Up to 2x 4th Generation Intel® Xeon® Scalable Processors with up to 52 cores per processor.
Memory:
- Up to 4TB with 32 x 128GB DDR5-5600 DIMMs, in a 2-socket configuration with 5th Gen. Intel® Xeon® Scalable Processors or
- Up to 4TB with 32 x 128GB DDR5-4800 DIMMs, in a 2-socket configuration with 4th Gen. Intel® Xeon® Scalable Processors.
- Connect USB-enabled devices via 2 USB ports
- DDR5 SDRAM slot for convenient installation of memory
- With NVMe interface get superb reliability and high-speed data transfer
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Perform computational tasks effectively accrediting the Xeon Platinum processor
Especificaciones técnicas
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Controllers | |
| Controller Type | NVMe |
| 12Gb/s SAS | |
| RAID Supported | No |
| Display & Graphics | |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| I/O Expansions | |
| Number of Total Expansion Bays | 10 |
| "Number of 2.5"" Bays" | 10 |
| Number of M.2 Interfaces | 2 |
| Memory | |
| Maximum Memory Supported | 4 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 32 |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Frequency | 50 Hz |
| 60 Hz | |
| Storage | |
| Supported Storage Drive Interfaces | PCI Express NVMe |
| SAS-3 | |
| Serial ATA | |
| Supported Storage Drive Types | SSD |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Number of Serial Ports | 1 |
| Number of VGA Ports | 1 |
| Physical Characteristics | |
| Weight (Approximate) | 51.90 lb (23540 g) |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 16.90" (429.26 mm) |
| Depth | 30" (762 mm) |
| Processor | |
| Processor Supported | Xeon Silver |
| Xeon Gold | |
| Xeon Platinum | |
| Xeon Bronze | |
| 64-bit Processing | Yes |
| Number of Processors Supported | 2 |
| General Information | |
| Product Type | Barebone System |
| Manufacturer Part Number | HCIAF220C-M7SN |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | Compute Hyperconverged with Nutanix HCIAF220C M7 Barebone System |
| Product Series | HCIAF220C M7 |
| Brand Name | Cisco |
