Soporte de pared Chief ConnexSys LVS1U para pantalla plana DI

• Hang units on a single strut channel for quick row leveling
• • No need for horizontal spacers
  • Vertical measurement is simply the height of the display to the next rail
  • Compatible with most 1-5/8" sizes of channel strut
• Reduces installation time - especially for XL and recessed configurations
• Tool-free ClickConnect™ latching secures displays
• PowerZone™ provides 6 points of adjustment in one easy-to-access location at the top of the mount

ALIGNMENT

• PowerZone™ Adjustments
• • Height adjustment ±1" on each interface
  • Tilt adjustment at single pivot point, protects displays from twisting
  • Depth can be set between 4" and 7.4" from the wall, providing a range of "home positions" ideal for recessed installations
  • • Both sides adjust independently, compensating for imperfections in the wall
    • Walls can be out of alignment by up to 2" (horizontally)
  • 3 levels of lateral adjustment
• Mount left/right along rail
• Interface left/right along mount
• Lock in lateral guide for fine-tune adjustment using turn knobs, protecting screens from potential collisions

SERVICEABILITY

• RapidDraw™ Display Release
• • Cord release system gently and remotely pops any screen out for easy access and can be extended 13.4" for service
  • Protects displays by not requiring an aggressive push to release/pop-out
  • Releases only on demand, preventing accidental pop-outs
  • Cord can be set up to pull for release from any 90 degree angle
• Kickstand provides 20 degrees of bottom tilt access

RIGIDITY

• Rigid frame keeps displays where you set them, even after extending for service
• Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes
