Acerca del producto
Compatible with Select Eaton 5kVA/6kVA 9PX UPS Systems
The MBP6K208 works with Eaton's 9PX5K, 9PX6K and 9PX3K3UN UPS systems. The bypass switch lets you service or replace the UPS system without powering down any equipment and risking costly downtime. Power passes directly from a PDU to equipment.
Versatile Connection and Installation Options
The MBP6K208 features hardwired input and output connections. Two NEMA L6-30R outlets also allow load connection. You can mount the maintenance bypass switch in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit. You can also adapt it for tower or wall installation using the included hardware.
- Isolates UPS from connected loads for maintenance without powering down equipment
- Designed for 3U rack, tower or wall mounting using the included installation hardware
- Compatible with Eatons 9PX5K, 9PX6K and 9PX3K3UN UPS systems
Especificaciones técnicas
| Power Description | |
| Input Voltage | 208 V AC |
| Miscellaneous | |
| Compatibility | Eaton 5kVA and 6kVA 9PX UPS |
| Country of Origin | Morocco |
| Physical Characteristics | |
| Weight (Approximate) | 8.40 lb (3810.18 g) |
| Form Factor | Rack-mountable |
| Rack Height | 3U |
| General Information | |
| Product Type | Bypass Switch |
| Manufacturer Part Number | MBP6K208 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Name | Bypass Switch |
| Brand Name | Eaton |
