Acerca del producto
A flexible low latency networking platform
The Cisco Nexus® 3550-F products are a compact yet powerful networking platform designed specifically for low-latency applications. The Nexus 3550-F products feature up to 48 ports of 10G Ethernet connectivity in a single-rack-unit form factor that can be configured as follows:
- Cisco Nexus 3550-F Modular Layer 1 Matrix Switch is purpose-built for low-latency data fan-out, electronic patch panels, and transparent monitoring applications. Layer 1 switching offers port-to-port latencies under 5ns.
- Cisco Nexus 3550-F Programmable Multiplexer Switch is designed to support multiple multiplexing modes for many-to-one aggregation use cases. Applications include low-latency link aggregation for financial trading order entry networks and low-latency telecommunications networks. This mode offers latencies as low as 39ns.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Rack mounting enables you to organize wires & secure cables for professional installation
- Built-in power supply to ensure all components are being supplied with accurate voltage
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Layer Supported | 1 |
| Interfaces/Ports | |
| Modular | Yes |
| Port/Expansion Slot Details | 48 x 10 Gigabit Ethernet Expansion Slot |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 48 |
| Total Number of Expansion Slots | 48.0 |
| Media & Performance | |
| Network Technology | 10GBase-X |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Physical Characteristics | |
| Weight (Approximate) | 24.25 lb (10999.614973 g) |
| Form Factor | Rack-mountable |
| Compatible Rack Unit | 1U |
| Miscellaneous | |
| Application/Usage | Enterprise |
| Network | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | N35F48X |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 3550-F |
| Product Name | Nexus 3550-F Ethernet Switch |
| Product Line | Nexus |
| Product Series | 3550 |
| Brand Name | Cisco |
| Power Description | |
| Input Voltage | 72 V DC |
| 40 V DC | |
| 230 V AC | |
| 120 V AC | |
| Power Source | Power Supply |
| DC | |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 150 W |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply Supported | Yes |
