Network Patch Pannel

Expected delivery 3 to 7 business days (exceptions applied)

Tripp Lite

Cable de conexión de canal de fibra de Tripp Lite

Name: Cable de conexión de canal de fibra de Tripp Lite
Brand: Tripp Lite
SKU: CBNE3281F
Price: 61.15 CAD
Availability: InStock

$61.15 CAD

~~$68.49 CAD~~ $61.15 CAD

-10% OFF Agotado

Los gastos de envío se calculan en la pantalla de pago.

Cable de conexión de canal de fibra de Tripp Lite - SC macho - SC macho - 30 m - Amarillo

VPN: N506-30M SKU: CBNE3281F CPU: 37332119582

Características Tipo de cable de fibra óptica
Este cable de red ofrece un rendimiento excelente y una conectividad clara.

Bloque de texto

Cantidad

Descuento por volumen disponible: solicite cotización.

Ver todos los detalles

Resumen de información del producto

Cable de conexión de canal de fibra de Tripp Lite

Acerca del producto

Tripp Lite's 30-meter multimode duplex Fibre Channel SC/SC patch cable is manufactured from 50/125 zipcord fiber. The cable has SC connectors on each end, a PVC jacket and is FDDI and OFNR rated. 50/125 Duplex multimode fiber is most commonly used in Fibre Channel applications. It is backward compatible with 62.5 micron fiber and built-in headroom for future applications. The cable provides higher bandwidth optimized for Gigabit and 10Gbps networks as well. Also available in 2, 3, 5, 10, 15, and 50 meter lengths. Search "N506-" to bring up all lengths. Also search "N516-" for SC-LC cables, and "N520-" for LC-LC cables. Tripp Lite warrants this product to be free from defects in materials and workmanship for life.

Features Fiber Optic cable type
This Network Cable provides splendid performance and clear connectivity

Especificaciones técnicas

Physical Characteristics
Product Color	Yellow
Color Family	Yellow
Miscellaneous
Additional Information	Number of fibers: 2 Fiber type: all glass graded index Core diameter: two 50+/-3 microns CLAD diameter: 125+/-2 microns Primary coating diameter: 245+/-15 microns Secondary coating diameter: 900+/-50 microns Attenuation @850NM: 3.5DB/KM maximum, @1300NM: 1.0DB/KM maximum Bandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimum Numeric apeture: .275 nominal Proof test level: 100,000 PSI Insertion loss testing performed on every connector (0.2db typical) and provided with cable Beveled edge on ends of glass makes insertion of plug a breeze
Package Contents	Fibre Channel Patch Cable 30M duplex MMF cable SC/SC 50/125 fiber
Certifications & Standards	FDDI OFNR
Country of Origin	China
General Information
Product Type	Network Cable
Manufacturer Part Number	N506-30M
Manufacturer Website Address	http://www.eaton.com/EatonCom/Markets/NorthAmerica
Manufacturer	Eaton Corporation
Product Name	Fibre Channel Patch Cable
Brand Name	Tripp Lite by Eaton
Technical Information
Cable Length	98.4 ft (29.99 m)
Jacket Type	Plenum
Cable Characteristic	Patch Cable
Cable Type	Fiber Optic
Connector Type on First End	SC Network - Male
Connector Type on Second End	SC Network - Male
Connector on First End Details	2 x SC Network - Male
Connector on Second End Details	2 x SC Network - Male
Fiber Optic Cable Core/Cladding Specification	50/125 µm
