Acerca del producto
The Cisco Nexus 92348GC-X Switch is a 1RU switch based on Cisco Cloud Scale technology and supports 0.696 Tbps of bandwidth and over 250 mpps. The 48 1GBASE-T downlink ports on the 9248GC-X can be configured to work as 100-Mbps, 1-Gbps ports. The 4 ports of SFP28 can be configured as 1/10/25-Gbps and the 2 ports of QSFP28 can be configured as 40- and 100-Gbps ports. The Cisco Nexus 92348GC-X is ideal for big data customers that require a Gigabit Ethernet ToR switch with local switching and for management switch use cases.
- 100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network backbone
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Quickly and easily set up a wired network with 54 networking ports
- Cascade to other network devices through the uplink port to expand your local area network
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Layer Supported | 3 |
| Power Description | |
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
| I/O Expansions | |
| Expansion Slot Type | SFP28 |
| QSFP28 | |
| Total Number of Expansion Slots | 6.0 |
| Physical Characteristics | |
| Weight (Approximate) | 14.12 lb (6404.724264 g) |
| Form Factor | Rack-mountable |
| Height | 1.72" (43.69 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 18.50" (469.90 mm) |
| Compatible Rack Unit | 1U |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 54 |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet Network |
| 2 x 100 Gigabit Ethernet Expansion Slot | |
| 4 x 25 Gigabit Ethernet Expansion Slot | |
| Media & Performance | |
| Network Technology | 100GBase-X |
| 10/100/1000Base-T | |
| 25GBase-X | |
| Ethernet Technology | 100 Gigabit Ethernet |
| 25 Gigabit Ethernet | |
| Gigabit Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | N9K-C92348GC-X |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 92348GC-X |
| Product Name | Nexus 92348GC-X Ethernet Switch |
| Product Line | Nexus |
| Product Series | 9200 |
| Brand Name | Cisco |
