Acerca del producto
Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.
Benefits
- Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime.
- Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
- Gather comprehensive power data at the palm of your hand with the use of the Vertiv VLC mobile app.
- Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a break in the network chain occurs. Supports up to 40 rPDUs.
- Every unit is 100% tested for reliability and functionality.
- A device fitted with multiple outputs for the distribution of electric power
- Before critical input source become overloaded always be warned with monitored PDUs
Especificaciones técnicas
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Management |
|
| Warranty | |
| Additional Warranty Information | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
| Miscellaneous | |
| Application/Usage | IT Equipment |
| Package Contents |
|
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Power Description | |
| Input Voltage | 230 V |
| 120 V AC | |
| Output Voltage | 120 V AC |
| Input Current | 30 A |
| Input Voltage Range | 100 V AC - 120 V AC |
| 200 V AC - 240 V AC | |
| Power Rating (Watt) | 8.60 kW |
| Physical Characteristics | |
| Form Factor | Hot-swappable |
| Length | 66.25" (1682.75 mm) |
| Mount Type | Rack-mountable |
| Width | 2" (50.80 mm) |
| Depth | 2.25" (57.15 mm) |
| Mounting Orientation | Vertical |
| Product Color | Blue |
| Color Family | Blue |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | NI30078B |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Packaged Quantity | 1 |
| Manufacturer | Vertiv |
| Product Model | MN03E4B1-24D203-3TL21A0A10-S |
| Product Name | rPDU MN03E4B1-24D203-3TL21A0A10-S 24-Outlets PDU |
| Product Series | rPDU |
| Brand Name | Vertiv Geist |
| Technical Information | |
| Features | LED Display |
| Protection Type | Single Pole |
| Overcurrent Protection | |
| Circuit Breaker | |
| Plug/Connector Type | NEMA L21-30P |
| Phase | Three Phase |
| Receptacle Type | NEMA 5-20R |
| PDU Type | Monitored |
| Receptacle Detail | 24 x NEMA 5-20R |
| Plug/Connector Detail | 1 x NEMA L21-30P |
