Acerca del producto
NMCs are cost-optimized, high density IO modules for use in Advantech's Network Application Platforms. A wide choice of GbE, 10GE and 40GE modules supporting copper and fiber interfaces with or without advanced LAN bypass gives our customers the flexibility to match varying deployment scenarios. Complementing a full range of network appliances supporting 1 to 8 NMC bays, these IO modules provide the scalability required to meet target price/performance ratios in even the most demanding use cases. At the same time, NMCs reduce the total cost of ownership and service cost via re-usability across the product range and multiple product generations. The option of factory and field installation enables upselling opportunities and "pay as you grow" concepts. Leveraging best-in-class Intel® Ethernet controller technology, NMCs provide a "it just works" user experience and a maximum of software compatibility.
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Up to 10x faster than standard Ethernet connection and provides high-performance
- With 10/100/1000Base-T technology, get up to 1000Mbps data transfer rate over twisted pair cable
Especificaciones técnicas
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Interfaces/Ports Details | 4 x RJ-45 10/100/1000Base-T LAN |
| Connector Type | RJ-45 |
| Total Number of Ports | 4 |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Physical Characteristics | |
| Form Factor | Plug-in Module |
| Height | 1.67" (42.40 mm) |
| Width | 2.94" (74.60 mm) |
| Depth | 6.88" (174.70 mm) |
| General Information | |
| Product Type | Network Module |
| Manufacturer Part Number | NMC-0121-04CBSA1 |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | NMC-0121 |
| Product Name | 4 Ports 1GbE RJ45 Thumbscrew Type with Advanced LAN Bypass |
| Brand Name | Advantech |
