- OMNISMART500 line interactive UPS system offers voltage regulation and battery support, plus complete AC and dialup/DSL line surge suppression
- Supports entry-level PC systems for up to 30 minutes during power failures to enable a safe system shutdown
- Supports a maximum load of 500VA/300 watts for 4 minutes and a half load of 250VA/150 watts for 14.6 minutes
- Automatic Voltage Regulation (AVR) circuits correct brownouts as low as 75 volts and overvoltages as high as 147 back to normal 120 volt levels without using battery power
- Attractive black tower configuration
- Includes 3 battery supported outlets, plus 3 additional surge suppression-only outlets, 6-ft. (1.83 m) AC line cord (all NEMA 5-15)
- USB port enables data-saving unattended shutdown when used with PowerAlert software, available via FREE download from tripplite.eaton.com/products/power-alert
- HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and macOS
- Supports WatchDog Service Monitoring/Rebooting Software (part# WATCHDOGSW)
- Dataline suppression jacks protect a single dialup phone/DSL line
- Audible alarm and 4 front panel LEDs indicate UPS system and line power status
- 500VA/300 watt power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment
- Supports battery replacement via built-in access panel
- Compatible with 120V/60 Hz applications for USA, Canada, Mexico and more
- Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
- Short circuit protection during AC and battery modes
- 300 W load capacity - backup power for your valuable electronics
- 500 VA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 4 minute at full load
Especificaciones técnicas
| Controls/Indicators | |
| Status Indicators | LED Indicators:
|
| Interfaces/Ports | |
| USB (HID Compliant) Port | Yes |
| Environmental Conditions | |
| Thermal Dissipation | 53 BTU/h |
| Maximum Operating Temperature | 104°F (40°C) |
| Management | |
| Alarm | Power Failure |
| Low Battery | |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Weight (Approximate) | 11.99 lb (5440 g) |
| Form Factor | Tower/Wall Mountable |
| Height | 8.50" (216 mm) |
| Width | 5" (127 mm) |
| Depth | 7.01" (178 mm) |
| Battery Information | |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 14.60 Minute |
| Backup/Run Time (Full Load) | 4 Minute |
| Battery Characteristics | Hot-swappable |
| Replaceable Battery | Yes |
| DC System Voltage | 12 V DC |
| Typical Battery Recharge Time | 3.60 Hour |
| General Information | |
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | OMNI SMT500PNP |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | OMNISMART500 |
| Product Name | OMNISMART500 500VA Tower/Wall Mountable UPS |
| Product Line | OmniSmart |
| Brand Name | Tripp Lite by Eaton |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 115 V AC |
| 110 V AC | |
| 120 V AC | |
| Surge Energy Rating | 480 J |
| Waveform Type | Sine Wave |
| Output Frequency | 60 Hz |
| Load Capacity (VA) | 500 VA |
| Load Capacity (Watt) | 300 W |
| Technical Information | |
| Application/Usage | Telecommunication |
| Network | |
| Electronic Device | |
| Computer | |
| Dataline Protection | RJ-11/RJ-45 |
| Plug/Connector Type | NEMA 5-15P |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-15R |
| EMI/RFI Noise Filter | Yes |
| AVR | Yes |
| Energy Saving | Greater than 95% efficiency |
| Transfer Time | 2.40 ms |
| Receptacle Detail | 6 x NEMA 5-15R |
