Acerca del producto
The Panduit® SmartZone™ G5 iPDU is more than a power distribution unit and energy monitoring device. These iPDUs monitor the data center power and environment (at the rack or cabinet level), by continuously scanning for electrical circuit overloads, and physical environmental conditions that place critical IT equipment at risk. Panduit's iPDUs provide comprehensive, accurate, energy measurement data to efficiently use power resources, make informed capacity planning decisions, improve uptime, measure PUE (power usage effectiveness), and drive green data center initiatives to save energy and money.
Making the right choice in IT equipment is essential for a safe, efficient data center operation. Our full range of iPDUs, environmental sensors, and dual locking power cords are the key to fulfilling mission-critical data center needs.
Making the right choice in IT equipment is essential for a safe, efficient data center operation. Our full range of iPDUs, environmental sensors, and dual locking power cords are the key to fulfilling mission-critical data center needs.
- PDU is reliable for power protection and management solutions
- PDU distributes AC power to multiple servers and balances the load on the servers
- Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
Especificaciones técnicas
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Physical Characteristics | |
| Form Factor | Hot-swappable |
| Length | 1.70" (43.18 mm) |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Width | 17.50" (444.50 mm) |
| Depth | 10.60" (269.24 mm) |
| Power Description | |
| Input Voltage | 415 V AC |
| Output Voltage | 120 V AC |
| 240 V AC | |
| Input Current | 30 A |
| Output Voltage Range | 120 V AC - 240 V AC |
| Power Rating (VA) | 17.30 kVA |
| Technical Information | |
| Protection Type | Overload Protection |
| Plug/Connector Type | NEMA L22-30P |
| Phase | Three Phase |
| Receptacle Type | IEC 60320 C19 |
| PDU Type | Monitored |
| Receptacle Detail | 6 x IEC 60320 C19 |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | P06D02M |
| Manufacturer Website Address | http://www.panduit.com |
| Manufacturer | PANDUIT CORP |
| Product Name | SmartZone MI 6-Outlets PDU |
| Product Line | SmartZone |
| Product Series | MI |
| Brand Name | Panduit |
