Acerca del producto
- PDU provides active metering enabling energy optimization and circuit protection
- Before critical input source become overloaded always be warned with monitored PDUs
Especificaciones técnicas
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Output Voltage | 208 V AC |
| Input Current | 20 A |
| Input Voltage Range | 100 V AC - 240 V AC |
| Power Rating (VA) | 3.30 kVA |
| Power Rating (Watt) | 3.30 kW |
| Technical Information | |
| Plug/Connector Type | NEMA L6-20P |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13 |
| IEC 60320 C19 | |
| PDU Type | Monitored |
| Receptacle Detail | 4 x IEC 60320 C19 |
| 20 x IEC 60320 C13 | |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | P24D24MBU1A |
| Manufacturer Website Address | http://www.panduit.com |
| Packaged Quantity | 1 |
| Manufacturer | PANDUIT CORP |
| Product Name | SmartZone G5 24-Outlets PDU |
| Product Line | SmartZone |
| Product Series | G5 |
| Brand Name | Panduit |
| Physical Characteristics | |
| Weight (Approximate) | 15.87 lb (7200 g) |
| Mount Type | Rack-mountable |
| Cord Length | 3.3 ft (1 m) |
| Height | 58.60" (1488.44 mm) |
| Width | 2" (50.80 mm) |
| Depth | 2.10" (53.34 mm) |
| Mounting Orientation | Vertical |
| Product Color | Blue |
| Color Family | Blue |
