4K HDMI Cable Connects Industrial and Outdoor Security and Digital Signage Components
This high-speed HDMI cable securely connects HDMI-enabled laptops, tablets, Blu-ray players, game consoles, media servers or security cameras to HDTVs, HD monitors, projectors or home theater receivers. Because the cable uses optical fiber, it can transmit HDMI signals longer distances with no latency or loss. It also eliminates any EMI/RFI line noise that can interfere with your audio/video signal and disrupt the performance of your connected equipment.
Transmits Crystal-Clear 4K Video with HDR and 4:4:4 Color
The P568FA-20M is rated up to 18 Gbps and supports Ultra HD resolutions up to 3840 x 2160 (4K x 2K) at 60 Hz, as specified in HDMI 2.0. High Dynamic Range (HDR) provides a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your 4K display. HDCP 2.2 compliance allows you to stream 4K Amazon and Netflix content with no complications. The cable also supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor, as well as other current HDMI standards, including 3D, 48-bit Deep Color and Dolby 5.1-channel surround sound.
Armored Cable Jacket Ideal for Areas Where Extra Protection Is Needed
The outer thermoplastic polyurethane (TPU) jacket offers UV protection for applications in which the cable is installed outdoors. The crush-resistant stainless steel armored tube protects the cabling against excessive force. The DuPont Kevlar resists heat and provides tensile strength to the cable when it is being bent or pulled. This type of cable construction provides ideal protection in outdoor applications where the cable is exposed to crushing, cuts and abrasion.
Advanced Fiber Cable Is Easier to Install than Copper
Because the fiber cable is slimmer and more flexible than standard copper HDMI cables, the P568FA-20M is easier to install around corners and in hard-to-reach spaces behind equipment. It draws power from the connected device, so no external power supply is needed to transmit the HDMI signal across the longer distances unique to fiber optic cabling
- Features AOC Technology
- Offers exceptional quality as well as upright compatibility with audio and video equipment
- Features Fiber Optic cable type
Especificaciones técnicas
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Physical Characteristics | |
| Shipping Weight (Approximate) | 2.90 lb (1315.42 g) |
| Shipping Height | 2.80" (71.12 mm) |
| Shipping Width | 8.70" (220.98 mm) |
| Jacket Material | Thermoplastic Polyurethane (TPU) |
| Product Color | Black |
| Color Family | Black |
| General Information | |
| Product Type | A/V Cable |
| Manufacturer Part Number | P568FA-20M |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | P568FA-20M |
| Product Name | P568FA-20M Fiber Optic Audio/Video Cable |
| Brand Name | Tripp Lite by Eaton |
| Technical Information | |
| Cable Length | 65.6 ft (20 m) |
| Data Transfer Rate | 18 Gbit/s |
| Device Supported | Video Surveillance System |
| Media Server | |
| Monitor | |
| Notebook | |
| Projector | |
| Receiver | |
| Security Camera | |
| HDTV | |
| Gaming Console | |
| Blu-ray Player | |
| Audio/Video Device | |
| Tablet | |
| Home Theater System | |
| Jacket Type | Armored |
| Features | Tensile Strength |
| HDCP 2.2 | |
| Stranded | |
| Abrasion Resistant | |
| Active | |
| Bendable | |
| Crush Resistant | |
| Cut Resistant | |
| EMI/RF Protection | |
| Flexible | |
| AOC Technology | |
| UV Protected | |
| HDR Support | |
| Heat Resistant | |
| Cable Type | Fiber Optic |
| Connector Type on First End | HDMI 2.0 Digital Audio/Video - Male |
| Connector Type on Second End | HDMI 2.0 Digital Audio/Video - Male |
| Supported Resolution | 3840 x 2160 |
| Contact Plating | Gold |
| Connector on First End Details | 1 x HDMI 2.0 Digital Audio/Video - Male |
| Connector on Second End Details | 1 x HDMI 2.0 Digital Audio/Video - Male |
