The P585-003 Mini DisplayPort Extension Cable (M/F) attaches to your current mDP cable to extend it by three feet. It supports Ultra High Definition video resolutions up to 3840 x 2160 (4K x 2K) at 60 Hz, allowing you to stream digital video and audio to an mDP display from an mDP computer, such as a MacBook® or Surface® Book, or tablet, including Microsoft's Surface Pro 4. The P585-003 connects to any computer, laptop, mobile device or display that features an mDP, Thunderbolt or Thunderbolt 2 port.
Premium foil and braid shielding delivers reliable, error-free signal quality and protection from EMI/RFI interference. Molded nickel-plated connectors with gold-plated contacts ensure excellent conductivity. Integral strain relief ensures the cable and connectors last a long time. A flexible PVC jacket protects twisted 32 AWG data lines and 32 AWG power lines.
Features
Extends an Existing Mini DisplayPort Cable an Extra 3 Ft.
- Female connector attaches to current mDP cable to add length
- Supports UHD video resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz
- Supports DisplayPort v1.2a and HDCP 2.2
- Recommended for devices with mDP, Thunderbolt or Thunderbolt 2 ports
First-Rate Construction for Superior Signal Transfer
- Premium foil and braid shielding for EMI/RFI noise protection
- Molded nickel-plated connectors and gold-plated contacts for optimal signal quality
- Integral strain relief for long life
- Twisted 32/32 AWG data/power lines
- Flexible PVC jacket and small footprint for easy installation in tight spaces
- Features Flexible
- Offers exceptional quality as well as upright compatibility with audio and video equipment
Especificaciones técnicas
| Miscellaneous | |
| Compatibility | Microsoft's Surface Pro 4 |
| Country of Origin | China |
| Physical Characteristics | |
| Shipping Weight (Approximate) | 3.20 oz (90.72 g) |
| Shipping Height | 0.50" (12.70 mm) |
| Shipping Width | 7" (177.80 mm) |
| Product Color | Black |
| Color Family | Black |
| General Information | |
| Product Type | A/V Cable |
| Manufacturer Part Number | P585-003 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | P585-003 |
| Product Name | P585-003 Mini DisplayPort Extension Cable (M/F), 3 ft |
| Brand Name | Tripp Lite by Eaton |
| Technical Information | |
| Cable Length | 3 ft (0.91 m) |
| Device Supported | Notebook |
| Tablet | |
| MacBook | |
| Audio/Video Device | |
| Shielding | Yes |
| Features | Strain Relief |
| Noise Protection | |
| Molded | |
| Flexible | |
| EMI/RF Protection | |
| Cable Characteristic | Extension Cable |
| Cable Type | Mini DisplayPort |
| Connector Type on First End | Mini DisplayPort 1.2a Digital Audio/Video - Male |
| Connector Type on Second End | Mini DisplayPort 1.2a Digital Audio/Video - Female |
| Connector Plating | Nickel |
| American Wire Gauge | 32 AWG |
| Supported Resolution | 3840 x 2160 |
| Contact Plating | Gold |
| Connector on First End Details | 1 x Mini DisplayPort 1.2a Digital Audio/Video - Male |
| Connector on Second End Details | 1 x Mini DisplayPort 1.2a Digital Audio/Video - Female |
