Acerca del producto
Ideal for health, safety, environment (HSE) applications within potentially combustible areas, this robust PTZ camera includes early smoke and fire detection analytics. It has worldwide certifications for use in Class I/II/III Division 1 and Zone 1,21.
Protect your personnel and production
Featuring smoke alert analytics, AXIS XPQ1785 serves as an additional layer of safety, monitoring for signs of smoke or fire. If detected, operators are alerted so they can assess the situation to determine appropriate responses. Additionally, it allows you to safeguard the production processes from a distance. This helps ensure that you only send personnel into restricted, potentially combustible environments when necessary.
Total situational awareness
AXIS XPQ1785 offers HDTV 1080p resolution at up to 60 fps. It features 32x optical zoom and a continuous 360° pan and +/- 90° tilt rotation for fast camera repositioning and smooth, continuous tracking of objects. It's got Axis Forensic WDR for clarity even when there are both dark and light areas in the scene. Thanks to Lightfinder, you get sharp, color images in low light. And Axis Zipstream provides exceptional savings on bandwidth and storage requirements without compromising image quality. Plus, electronic image stabilization keeps the picture steady when the camera is exposed to vibrations.
Globally certified and suitable for all environments
AXIS XPQ1785 is a globally certified Class I/II/III Division 1 and Zone 1,21 stainless steel (316L) PTZ camera for use in hazardous areas (according to NEC, CEC, IECEx, ATEX, and more). It can withstand wide temperatures ranging from -60°C to 60°C (-76°F to 140°F). And, it's IP66, IP67, IP68-rated for protection against water and dust ingress. Furthermore, ease of installation is supported by a compact and low-weight design, with both RJ45 and SFP for fiber or coax and 110-240 V AC power input.
- Features RGB CMOS sensor
- Up to 1920 x 1080 video resolution
Especificaciones técnicas
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | AC |
| Storage | |
| Storage Type | Memory Card |
| Exposure | |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/66500 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Type | RGB CMOS |
| Field of View | Horizontal field of view: 60°-2.3° Vertical field of view: 39°-1.3° |
| Environmental Conditions | |
| Minimum Operating Temperature | -76°F (-60°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 100% |
| Technical Information | |
| Recording Formats | Full HD |
| Night Vision | Yes |
| HD Recording | Yes |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 02278001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | XPQ1785 |
| Product Name | XPQ1785 Explosion-Protected PTZ Camera |
| Brand Name | AXIS |
| Lens | |
| Lens Type | Varifocal |
| Optical Zoom | 32x |
| Maximum Aperture | f/1.4 |
| Maximum Focal Length | 137 mm |
| Minimum Focal Length | 4.3 mm |
| Minimum Aperture | f/4 |
| Lens Included | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 23 kg |
| Durability | Explosion Proof |
| Weather Proof | |
| Form Factor | Turret |
| Mount Type | Wall Mount |
| Pole Mount | |
| Height | 14.60" (370.84 mm) |
| Width | 9.40" (238.76 mm) |
| Depth | 11.90" (302.26 mm) |
| Video | |
| Video Formats | MJPEG |
| H.264 | |
| H.264B | |
| H.264B (MPEG-4 Part 10/AVC) | |
| Motion JPEG | |
| Zipstream | |
| H.264M | |
| H.264M (MPEG-4 Part 10/AVC) | |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 60 fps |
| Miscellaneous | |
| Features | Wide Dynamic Range |
| White Balance | |
| Video Management System | |
| Smoke Detector | |
| Day/Night | |
| Password Protection | |
| PTZ | |
| Defog | |
| Electronic Image Stabilization | |
| Cross Line Detection | |
| HTTPS Encryption | |
| Motion Detection | |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK08 |
| IK10 | |
| Ingress Protection Rating | IP66 |
| IP67 | |
| IP68 |
