Acerca del producto
This sturdy 4K camera is the world's first explosion-protected camera designed for Zone/Division 2. Ideal for health and safety applications as well as operational efficiency, it supports deep-learning based analytics that run on the edge.
A camera that's fit for its purpose
Designed and certified for Zone and Division 2 hazardous locations (Zone 2,22 and Class I/II/III Division 2 according to ATEX/IECEx/cULus), this multitasking camera provides many benefits within health and safety applications as well as operational efficiency. For instance,smoke alert analyticsmonitors for signs of smoke or fire in potentially combustible environments. In operational efficiency applications, it can help increase efficiency, maintain peak operability, and maximize uptime. For instance, you can gain deeper understanding and awareness by creating an advanced data-driven sensory network that integrates with existing sensors and systems.
Deep learning-based analytics run on the edge
Built on ARTPEC-8, it includes adeep learning processing unit (DLPU)enabling advanced features and powerful analytics that run on the edge. For instance, by connecting the camera to the process control system and continuously monitoring a process, you can fine-tune the process in real-time to maximize throughput. Plus, you'll be able to extract and sendmetadata, which can be used for trend monitoring and predictive maintenance.
Excellent image quality day or night
AXIS P1468-XLE offers outstanding 4K resolution at up to 60 fps. Thanks toLightfinder 2.0andForensic WDR, it delivers true colors and great forensic detail in challenging light or near darkness. And, with a large 1/1.2" sensor it ensures great light sensitivity.OptimizedIRenables surveillance in total darkness up to 40 m (131 ft) without the need for extra lighting. Plus, motion-adaptive exposure reduces the motion blur from approaching or nearby objects. Furthermore,Zipstreamwith support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.
Secure and sturdy in hazardous areas
Compact and lightweight in design, this explosion-protected camera is easy to install. It offersbuilt-in cybersecurity featuresto help prevent unauthorized access and safeguard your system. For instance, AxisEdge Vaultprotects your Axis device ID and simplifies authorization of Axis products on your network. Furthermore, this sturdy, impact-resistant camera is IP66/67,NEMA 4X, and IK10-rated for protection against dust, rain, snow, and impacts. Plus, it can withstand winds up to 50 m/s.
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- Up to 3840 x 2160 video resolution
- Up to 131.23 ft (40 m) of night vision
- Network camera - Helps achieve high-quality video results
Especificaciones técnicas
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Storage | |
| Storage Type | Memory Card |
| Exposure | |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/66500 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 100% |
| Power Description | |
| Input Voltage | 28 V DC |
| Power Source Type | DC |
| PoE | |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Size | 1/1.2" |
| Image Sensor Type | CMOS |
| Field of View | Horizontal field of view 108 - 49 ° / Vertical field of view 58 - 27 ° |
| Technical Information | |
| Recording Formats | 4K |
| Night Vision | Yes |
| HD Recording | Yes |
| Night Vision Distance | 131.23 ft (40 m) |
| Night Vision Type | Infrared |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 02534001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | P1468-XLE |
| Product Name | P1468-XLE Explosion-Protected Bullet Camera |
| Brand Name | AXIS |
| Lens | |
| Lens Type | Varifocal |
| Optical Zoom | 2.1x |
| Maximum Aperture | f/1.6 |
| Maximum Focal Length | 12.9 mm |
| Minimum Focal Length | 6.2 mm |
| Minimum Aperture | f/2.9 |
| Lens Included | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 1.30 kg |
| Durability | Impact Resistant |
| Weather Resistant | |
| Explosion Proof | |
| Form Factor | Bullet |
| Diameter | 5.20" (132 mm) |
| Product Color | Black |
| Color Family | Black |
| Miscellaneous | |
| Features | PTZ |
| SD Card Local Storage | |
| Shock Detection | |
| Vehicle Detection | |
| Video Management System | |
| Wide Dynamic Range | |
| Audio Detection | |
| Built-in IR LED | |
| Day/Night | |
| Human Detection | |
| Motion Detection | |
| TAA Compliant | Yes |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| IP67 | |
| Video | |
| Video Formats | H.265 (MPEG-H Part 2/HEVC) |
| H.265B | |
| H.265H | |
| H.265M | |
| Motion JPEG | |
| Zipstream | |
| H.265 | |
| H.264M (MPEG-4 Part 10/AVC) | |
| H.264M | |
| H.264H (MPEG-4 Part 10/AVC) | |
| H.264 | |
| H.264B (MPEG-4 Part 10/AVC) | |
| H.264H | |
| H.264B | |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 60 fps |
