Acerca del producto
Do you need a camera that ensures complete coverage and excellent image quality with no blind spots? Built on ARTPEC-8, this multisensor, cost-efficient camera supports advanced analytics based on deep learning on the edge
True to life images
This 7 MP multisensor camera offers a single smooth and cohesive video stream with 180° panoramic coverage and captures high resolution images with incredible details up to 30 fps. Thanks to horizon straightening, it ensures visually balanced images. Plus, the operator's viewing experience will be more natural due to the straightened horizon in the image. With seamless stitching across all 4 images, it delivers a coherent-looking image in one single video stream for a perfect overview without any stitch in the center. And the camera automatically optimizes white balance and exposure time. Furthermore, thanks toForensic WDR, it offers excellent forensic image usability.
Complete coverage with support for audio input
AXIS P3827-PVE is perfect when you need to see the whole picture. It offers panoramic overview of extensive areas with 180° horizontal and 90° vertical coverage with no blind spots. And it's possible to mount two cameras back-to-back for a complete 360° overview using AXIS T94V01C Dual Camera Mount. This allows for quick and intuitive situational awareness over a large area and lets the operator visually follow objects across great distances. Furthermore, withedge-to-edgetechnology, it's easy to add whatever connectivity devices you need. For instance, you can add support for audio using AXIS T61 Audio and I/O Interface.
Deep learning on the edge
Built on ARTPEC-8, this high-performance camera includes adeep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before-on the edge. Plus, it delivers valuablemetadatafacilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, AXIS P3827-PVE can detect and classify humans, vehicles, and types of vehicles-all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.
Cost-efficient, flexible, and secure
This cost-efficient camera gives you get the benefits of four cameras while paying for just one. And fewer cameras are needed to cover large areas. Additionally, it offers a wide variety of mounting options and adjustable positions to ensure fast, cost-efficient, and easy installation. Furthermore, AXIS P3827-PVE includes built-incybersecurityfeatures. For instance, AxisEdge Vaultprotects your Axis device ID and simplifies authorization of Axis devices on your network. And, for added peace of mind, it includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified.
- Features RGB CMOS sensor
- Up to 3712 x 1856 resolution for surveillance in real-time
- Network camera - Helps achieve high-quality video results
Especificaciones técnicas
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Storage | |
| Storage Type | Memory Card |
| Technical Information | |
| HD Recording | Yes |
| Warranty | |
| Additional Warranty Information | Axis 5-year warranty |
| Exposure | |
| Longest Shutter Speed | 1.5 Second |
| Shortest Shutter Speed | 1/31500 Second |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Maximum Operating Humidity | 100% |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | DC |
| PoE | |
| Lens | |
| Lens Type | Fixed |
| Maximum Aperture | f/2.0 |
| Maximum Focal Length | 3.3 mm (0.13") |
| Lens Included | Yes |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Size | 1/2.8" |
| Image Sensor Type | RGB CMOS |
| Effective Camera Resolution | 7 Megapixel |
| Field of View | Horizontal field of view: 180° Vertical field of view: 90° |
| Number of Sensors | 4 |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 02450001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | P3827-PVE |
| Product Name | P3827-PVE Panoramic Camera |
| Product Line | Panoramic |
| Brand Name | AXIS |
| Physical Characteristics | |
| Weight (Approximate) | 5.07 lb (2300 g) |
| Form Factor | Dome |
| Mount Type | Conduit Mount |
| Bracket Mount | |
| Ceiling Mount | |
| Junction Box Mount | |
| Wall Mount | |
| Diameter | 7.68" (195 mm) |
| Height | 6.65" (169 mm) |
| Product Color | White |
| Color Family | White |
| Video | |
| Video Formats | H.264H |
| H.264B (MPEG-4 Part 10/AVC) | |
| H.264B | |
| H.265 | |
| H.264M (MPEG-4 Part 10/AVC) | |
| H.264H (MPEG-4 Part 10/AVC) | |
| H.264 | |
| Zipstream | |
| Motion JPEG | |
| H.265M | |
| Maximum Video Resolution | 3712 x 1856 |
| Maximum Frame Rate | 30 fps |
| Miscellaneous | |
| Package Contents |
|
| Features | Auto Gain Control |
| Audio Detection | |
| 3D Noise Reduction | |
| Wide Dynamic Range | |
| Tampering Alarm | |
| PTZ | |
| Noise Detection | |
| 2D Noise Reduction | |
| Multi-view Stream | |
| Motion Detection | |
| Country of Origin | Mexico |
| TAA Compliant | Yes |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| IP67 | |
| Network & Communication | |
| Protocols | RFC 3164/5424 |
| RTCP | |
| RTP | |
| RTSP | |
| SFTP | |
| SMTP | |
| SNMPv1/v2c/v3 (MIB2) | |
| SRTP | |
| TCP | |
| TLS | |
| UDP | |
| 802.1X | |
| Bonjour | |
| CIFS/SMB | |
| DDNS | |
| DiffServ (QoS) | |
| DNS/DNSv6 | |
| FTP | |
| HTTP | |
| UDP/TCP/TLS | |
| UPnP | |
| ZeroConf | |
| HTTPS | |
| ICMP | |
| ICMPv4/ICMPv6 | |
| IGMPv1/v2/v3 | |
| IPv4 | |
| IPv6 USGv6 | |
| mDNS | |
| NTP | |
| NTS | |
| QoS | |
| Connectivity Technology | Wired |
| Ethernet Technology | Gigabit Ethernet |
| Remote Management | Yes |
