Introduction
WISE-2410 is a LoRaWAN wireless condition monitoring sensor integrated with an ARM Cortex-M4 processor, LoRa transceiver, 3-axis accelerometer and temperature sensor. It balances the wireless bandwidth between WISE-2410 and the gateway, so it also mitigates the data transmission fail rates between edge-devices and gateways.
Star Topology
WISE-2410 is a LoRaWAN uses a star network topology and features a gateway data relay function between sensors and the application server. The communication between the sensors and gateway goes over the wireless channel, utilizing the LoRa physical layer, whilst the connection between the gateways and the central server are handled over a backbone IP-based network or over Modbus protocol to the application server
Computing on Board
With an ARM Cortex-M4 Processor, WISE-2410 enables users to implement more features inside. WISE-2410 is able to calculate more complex eigenvalues itself, such as VRMS, ARMS, Peak, Displacement, Kurtosis, Crest factor, Skewness and Standard Deviation values. With its edge computing capability, WISE-2410 can balance the loading between WISE2410, gateway, and cloud service.
Plug & Play with 2-year Battery life cyle
WISE-2410 includes two 3.6V AA battery holders. Along with LPWAN technology verified by Advantech, the battery life on WISE-2410 can be up to 2 years with once per hour data update interval time. With IP66 protection design, WISE-2410 is ideal for Low-Power Wide-Area Network (LPWAN) applications, such as pumps, HAVC system, motors, facility monitoring and more. WISE-2410 connects to Advantech's WISE Studio Utility for more user friendly and efficient installation.
- oRaWAN wireless connectivity
- Built-in 3-axis accelerometer and temperature sensor
- On-board computing. Directly sends VRMS, ARMS, Peak, Displacement, Kurtosis, Crest factor, Skewness and Standard Deviation values to applications
- Support battery power supply, no wiring installation needed
- Easy settings with user friendly interfaces on WISE Studio utility
- ISO 10816-1 compliant
- Support wide temperature -20 ~ 80 °C (Battery-powered)
- IP66 enclosure design
Especificaciones técnicas
| Physical Characteristics | |
| Dimensions | Dimension (H x D):
|
| Power Description | |
| Power Source | Batteries |
| Battery Information | |
| Battery Included | No |
| Battery Voltage | 3.6 V DC |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Ingress Protection Rating | IP66 |
| Technical Information | |
| Connectivity Technology | Wireless |
| Recommended Usage | Studio |
| Environmental Conditions | |
| Minimum Operating Temperature | -4°F (-20°C) |
| Maximum Operating Temperature | 176°F (80°C) |
| Minimum Storage Temperature | -13°F (-25°C) |
| Maximum Storage Temperature | 194°F (90°C) |
| Maximum Relative Humidity (Non-condensing) | 95% |
| General Information | |
| Product Type | Starter Kit |
| Manufacturer Part Number | WISE2410SKNA |
| Manufacturer Website Address | http://www.advantech.com |
| Packaged Quantity | 1 Box |
| Manufacturer | Advantech Co., Ltd |
| Product Name | LoRaWAN Wireless Condition Monitoring Starter Kit |
| Brand Name | Advantech |
