| Environmental Conditions |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Network & Communication |
| Ethernet | Yes |
| Remote Management | Yes |
| Power Description |
| Power Source | DC Supply |
| Power Consumption | 90 W |
| Software |
| Operating System Supported | Android |
| ChromeOS |
| Apple iOS |
| Physical Characteristics |
| Height | 1.77" (45 mm) |
| Width | 12.99" (330 mm) |
| Depth | 11.22" (285 mm) |
| NVR Weight | 4.19 lb (1900 g) |
| Technical Information |
| Recording Formats | 4K |
| Connectivity Technology | Wired |
| Features | Motion Detection |
| HD Recording | Yes |
| Total Number of Channels | 16 |
| System Components | Network Video Recorder |
| Video |
| Video Formats | H.265 |
| H.264+ |
| H.264 |
| H.265+ |
| Maximum Resolution | 8MP |
| Maximum Frame Rate | 30 fps |
| Interfaces/Ports |
| USB | Yes |
| HDMI | Yes |
| Number of USB Ports | 2 |
| USB Standard | USB 2.0 |
| Number of VGA Out | 1 |
| Total Number of Audio In Ports | 1 |
| Total Number of Audio Out Ports | 1 |
| General Information |
| Product Type | Video Surveillance Station |
| Manufacturer Part Number | VIGI NVR2016H-16P |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | VIGI NVR2016H-16P |
| Product Name | VIGI 16 Channel PoE+ Network Video Recorder |
| Product Line | VIGI |
| Brand Name | TP-Link |
