Especificaciones técnicas
| Audio | |
| Audio Support | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Storage | |
| Internal Memory | 2 GB |
| Storage Type | Memory Card |
| Exposure | |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/66500 Second |
| PTZ Modes | Preset Point |
| Power Description | |
| Input Voltage | 52 V DC |
| 58 V DC | |
| Maximum Power Consumption | 185 W |
| Power Source Type | DC |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Size | 1/2.8" |
| Image Sensor Type | CMOS |
| Field of View | Visual: Horizontal field of view: 58.5°-2.4°Vertical field of view: 35°-1.3, Thermal 35 mm: Horizontal field of view: 17°Vertical field of view: 12.8° Vertical field of view: 13.5°-4.5° |
| Number of Sensors | 2 |
| Thermal Image Sensor Type | Uncooled Microbolometer |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 03053-001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | Q8752-E Mk II |
| Product Name | Q8752-E Mk II Bispectral PTZ Camera |
| Brand Name | AXIS |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 149°F (65°C) |
| Minimum Operating Humidity (Condensing) | 10% |
| Maximum Operating Humidity (Condensing) | 100% |
| Minimum Storage Humidity (Non-condensing) | 5% |
| Maximum Storage Humidity (Non-condensing) | 95% |
| Physical Characteristics | |
| Weight (Approximate) | 32.85 lb (14900 g) |
| Durability | Vandal Resistant |
| Weather Resistant | |
| Product Color | White |
| Color Family | White |
| Product Material | Aluminum |
| Germanium | |
| Glass | |
| Lens | |
| Lens Type | Fixed/Varifocal |
| Optical Zoom | 32x |
| Maximum Aperture | f/1.4 |
| Maximum Focal Length | 137.6 mm (5.42") |
| Minimum Focal Length | 4.3 mm (0.17") |
| Minimum Aperture | f/4 |
| Lens Included | Yes |
| Maximum Thermal Focal Length | 1.38" (35 mm) |
| Maximum Aperture (Lens 2) | f/1.2 |
| Video | |
| Video Formats | H.264M (MPEG-4 Part 10/AVC) |
| H.265 | |
| H.265 (MPEG-H Part 2/HEVC) Main Profile | |
| Motion JPEG | |
| Zipstream | |
| H.264H (MPEG-4 Part 10/AVC) | |
| H.264 | |
| H.264B (MPEG-4 Part 10/AVC) | |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 30 fps |
| Thermal Video Resolution | 640 x 480 |
| Miscellaneous | |
| Package Contents |
|
| Features | Day/Night |
| White Balance | |
| Vehicle Detection | |
| SD Card Local Storage | |
| Privacy Masking | |
| Password Protection | |
| Electronic Image Stabilization | |
| HTTPS Encryption | |
| Human Detection | |
| Ingress Protection | |
| Wide Dynamic Range | |
| Motion Detection | |
| TAA Compliant | Yes |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Technical Information | |
| Recording Formats | Full HD |
| Night Vision | Yes |
| HD Recording | Yes |
| Camera Iris | Auto |
| Languages Support | Portuguese |
| Traditional Chinese | |
| Thai | |
| Swedish | |
| Spanish | |
| Simplified Chinese | |
| Russian | |
| Vietnamese | |
| Turkish | |
| Polish | |
| Czech | |
| Dutch | |
| English | |
| Finnish | |
| French | |
| German | |
| Italian | |
| Japanese | |
| Korean | |
| Infrared (IR) Cut-off Filter | Yes |
| Night Vision Type | Infrared |
| Wide Dynamic Range Detail | 120 dB |
| Network & Communication | |
| Protocols | ZeroConf |
| ARP | |
| CDP | |
| CIFS/SMB | |
| DDNS | |
| DHCPv4/v6 | |
| DiffServ (QoS) | |
| DNS/DNSv6 | |
| FTP | |
| HTTP | |
| HTTP/2 | |
| HTTPS | |
| ICMP | |
| ICMPv4/ICMPv6 | |
| IEEE 802.1AR | |
| IEEE 802.1X (EAP-TLS) | |
| IGMPv1/v2/v3 | |
| IPv4 | |
| IPv6 USGv6 | |
| LLDP | |
| mDNS (Bonjour) | |
| MQTT | |
| MQTT v3.1.1 | |
| NTP | |
| NTS | |
| ONVIF | |
| RTCP | |
| RTP | |
| RTSP | |
| SFTP | |
| SMTP | |
| SNMPv1/v2c/v3 (MIB2) | |
| SRTP/RTSPS | |
| SSH | |
| Syslog | |
| TCP | |
| TLS | |
| UDP | |
| UPnP | |
| Connectivity Technology | Wired |
| Ethernet Technology | Gigabit Ethernet |
| Remote Management | Yes |
