Acerca del producto
The Supermicro PWS-802A-1R is an 80 Plus Titanium power supply capable of supplying 800W output power at 96% efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages. Features a card edge connector for connection with the backplane of compatible Supermicro 1U systems. This power supply is designed to not only provide you reliable power to your Supermicro server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 200,000 hours (at 25 C) and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. This power supply is redundant to safe-guard your system from power failure and allows for hot-swap replacement to eliminate system downtime. All materials contained comply with RoHS requirements and is certified by Supermicro.
Especificaciones técnicas
| Technical Information | |
| Efficiency | 96% |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.57" (40 mm) |
| Width | 2.99" (76 mm) |
| Depth | 13.23" (336 mm) |
| General Information | |
| Product Type | Redundant Power Supply |
| Manufacturer Part Number | PWS802A1R |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Name | 800W 1U Redundant Power Supply |
| Brand Name | Supermicro |
| Power Description | |
| Output Voltage | 12 V DC |
| 5 V | |
| Output Current | 66 A |
| 4 A | |
| Number of +12V Rails | 1 |
| Output Voltage Detail | 5 V @ 4 A |
| 12 V DC @ 66 A |
