Acerca del producto
The HPE Aruba Networking CX 9300 Switch Series provides 25.6Tbps, 1U fixed configuration that supports 32 ports of 100/400GbE. This series is designed to provide flexible, cost-effective, high-density 400GbE for servers, storage, and intra-fabric connectivity.
The HPE Aruba Networking CX 9300 Switch Series protects enterprises' investment as they as they transition server farms from 10GbE and 25GbE to 100GbE/400GbE EVPN-VXLAN spine configurations, with reduced power and a smaller footprint. It supports large data center pods of up to 6,000 x 25G servers or up to 2,000 x 100G servers. This is an significant jump in scaling/density over current HPE Aruba Networking CX 8325-32C, which scales to 700 x 25G servers.
Features | Maximize your HPE Aruba Networking CX 9300 Switch Series | What's New
- 25.6Tbps, 1U fixed configuration supporting 32 ports of 100/400GbE. Designed to provide flexible, cost-effective, high-density 10-400GbE for servers, storage, and intra-fabric connectivity.
- Protects enterprises' investment as they as they transition server farms from 10GbE and 25GbE to 100GbE/400GbE EVPN-VXLAN spine configurations, with reduced power and a smaller footprint.
- Support large data center pods connecting up to 6,000 x 25G servers or up to 2,000 x 100G servers.
- Support large data center pods and increased density by connecting up to 6,000 x 25G servers or up to 2,000 x 100G servers.
- HPE Aruba Networking Aruba Fabric Composer greatly simplifies the automation, orchestration, and end-end visibility of the network fabric underlay and virtualized overlay.
- Introducing new HPE Aruba Networking 9300S 32p QSFP28 100G 8p QSFP-DD 400G Back-to-Front and Front-to-Back Bundles along with new compatible transceivers and power supply options.
- 100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network backbone
- Rack mounting enables you to organize wires & secure cables for professional installation
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Built-in power supply to ensure all components are being supplied with accurate voltage
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Interfaces/Ports | |
| Port/Expansion Slot Details | 32 x 100/400 Gigabit Ethernet QSFP-DD Expansion Slot |
| 2 x 10 Gigabit Ethernet SFP+ Expansion Slot | |
| I/O Expansions | |
| Expansion Slot Type | QSFP-DD |
| SFP+ | |
| Number of SFP+ Slots | 2 |
| Total Number of Expansion Slots | 34 |
| Miscellaneous | |
| Application/Usage | Server |
| Network | |
| Data Center | |
| Enterprise | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Weight (Approximate) | 26.12 lb (11847.83 g) |
| Form Factor | Rack-mountable |
| Height | 23.23" (590.04 mm) |
| Width | 17.26" (438.40 mm) |
| Depth | 1.71" (43.43 mm) |
| Compatible Rack Unit | 1U |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| AC | |
| Power Consumption | 600 W |
| Number of Power Supplies Installed | 2 |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | R9A29A#B2E |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | CX 9300 Ethernet Switch |
| Product Series | CX 9300 |
| Brand Name | Aruba |
| Media & Performance | |
| Network Technology | 100GBase-X |
| 10GBase-X | |
| 25GBase-X | |
| Maximum Data Transfer Rate | 50 GB/s |
| Ethernet Technology | 10 Gigabit Ethernet |
| 400 Gigabit Ethernet | |
| 200 Gigabit Ethernet | |
| 25 Gigabit Ethernet | |
| 100 Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
