Acerca del producto
HPE Networking Comware Switch Series 5720 is designed to cater to diverse customer needs. This cost-effective access switch offers hybrid SFP+ and 10GBASE-T options, along with multigigabit support on 10GBASE-T ports, allowing scalability from 10GbE SFP+ to 100G QSFP28.
These data center leaf / access layer switches come with MACsec support and 10GBASE-T additional modules. Features such as distributed resilient network interconnect (DRNI) and HPE Intelligent Resilient Fabric (IRF) enhance network resiliency while redundant pluggable power supplies provide a dynamic and highly available network.
Moreover, these switches support HPE Intelligent Management Center (IMC), which delivers a consistent network manageability experience. Streamline network management processes for greater efficiency through centralized configuration, compliance, policy management, monitoring, and troubleshooting.
Features | Maximize your HPE Networking Comware Switch Series 5720 | What's New
- Cost-effective access switch with hybrid SFP+ and 10GBASE-T with multigigabit options on 10GBASE-T port-5G, 2.5G, 1G.
- DRNI combines multiple physical switches into one virtual distributed-relay (DR) system for doubling aggregate bandwidth, faster forwarding, resiliency, and high availability.
- Virtual Extensible LAN (VXLAN) with lite Ethernet VPN (EVPN) allows greater flexibility, better performance with wirespeed, enhanced security, and better scalability.
- Hardware-based MACsec enable end-to-end encrypted security.
- The Intelligent Resilient Fabric (IRF) technology enabling greater resilience and scalability with IRF stacking.
- VXLAN and EVPN enable isolation and greater scalability of L2/L3 overlay services and multicast.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Supports layer 3 switching for enhanced performance and usability
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 40 ports
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1x |
| I/O Expansions | |
| Expansion Slot Type | QSFP28 |
| SFP+ | |
| Number of SFP+ Slots | 8 |
| Total Number of Expansion Slots | 14 |
| Miscellaneous | |
| Application/Usage | Business |
| Data Center | |
| Enterprise | |
| Network | |
| Security | |
| Technical Information | |
| Features | Access Control List |
| Virtual Extensible LAN (VXLAN) | |
| In-Service Software Upgrade (ISSU) | |
| Hot-swappable | |
| High Availability Supported | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 40 |
| Port/Expansion Slot Details | 8 x 1/10 Gigabit Ethernet SFP+ Expansion Slot |
| 6 x 100 Gigabit Ethernet QSFP28 Expansion Slot | |
| 40 x 10BASE-T Gigabit Ethernet RJ-45 Network Port | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | S2N60A |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | Networking Comware Data Center Switch 40p 10GBASE-T 8p SFP+ 1G/10G 6p QSFP28 100G 5720 |
| Product Line | Comware |
| Product Series | 5720 |
| Brand Name | HPE |
| Power Description | |
| Input Voltage | -48 V DC |
| 230 V AC | |
| 120 V AC | |
| -60 V DC | |
| Power Source | Power Supply |
| AC/DC | |
| Power Consumption | 99 W |
| Redundant Power Supply Supported | Yes |
| Media & Performance | |
| Network Technology | 2.5GBase-T |
| 10GBase-X | |
| 10GBase-T | |
| 100GBase-X | |
| 1000Base-X | |
| 5GBase-T | |
| 1000Base-T | |
| Maximum Data Transfer Rate | 12.50 GB/s |
| Ethernet Technology | Gigabit Ethernet |
| 5 Gigabit Ethernet | |
| 2.5 Gigabit Ethernet | |
| 100 Gigabit Ethernet | |
| 10 Gigabit Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber |
