Acerca del producto
Omada Pro is an intelligent cloud solution for enterprise networking, offering enterprise-grade product line designed to meet the high-capacity, security, and management needs of various industries, such as MDUs, hospitality, K-12 education, public works, and more.
- 100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network backbone
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Management capability provides control over setup and configuration of your network
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Cascade to other network devices through the uplink port to expand your local area network
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Reliability | |
| MTBF | 382117 Hour |
| I/O Expansions | |
| Expansion Slot Type | QSFP28 |
| SFP28 | |
| Total Number of Expansion Slots | 28 |
| Miscellaneous | |
| Application/Usage | Enterprise |
| Network | |
| Retail | |
| Security | |
| Education | |
| Technical Information | |
| Features | Secure Boot |
| Surge Protection | |
| Loop Protection | |
| DHCP Snooping | |
| Hot-swappable | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 15" (381 mm) |
| Product Color | Gray |
| Color Family | Gray |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | S7500-24Y4C |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | S7500-24Y4C |
| Product Name | Omada Pro 24-Port 25G Stackable L3 Managed Aggregation/Core Switch with 4 100G Slots |
| Product Line | Omada Pro |
| Brand Name | TP-Link |
| Interfaces/Ports | |
| Uplink Port | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 1 x USB Type C Console Port |
| 1 × RJ-45 Console Port | |
| 2 × USB 3.0 USB Port | |
| 4 × 40/100 Gigabit Ethernet QSFP28 Expansion Slot | |
| 24 × 1/10/25 Gigabit Ethernet SFP28 Expansion Slot | |
| 1 × RJ-45 Management Port | |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1Q |
| IEEE 802.1p | |
| IEEE 802.1s | |
| IEEE 802.1w | |
| IEEE 802.1x | |
| IEEE 802.3ad | |
| IEEE 802.3x | |
| IEEE 802.1D | |
| IEEE 802.1ab | |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | AC |
| Power Supply | |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 137.63 W |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Redundant Power Supply Supported | Yes |
| Media & Performance | |
| Network Technology | 40GBase-X |
| 10GBase-X | |
| 1000Base-X | |
| 100GBase-X | |
| 25GBase-X | |
| Maximum Data Transfer Rate | 12.50 GB/s |
| Ethernet Technology | 10 Gigabit Ethernet |
| 100 Gigabit Ethernet | |
| 40 Gigabit Ethernet | |
| Gigabit Ethernet | |
| 25 Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
