Acerca del producto
The innovative SuperBlade® offers enhanced system computing density leveraged from years of rackmount server design experience. Applying Supermicro's application-optimized engineering philosophy, each SuperBlade® module delivers true server functionality including up to four processors (in select models), optional InfiniBand mezzanine HCA, and supports either SATA or SAS hard drives.
- DDR3 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
- With Serial ATA/300 interface get superb reliability and high-speed data transfer
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
Especificaciones técnicas
| Display & Graphics | |
| Graphics Controller Model | G200 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C602 |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
Electromagnetic Compatibility (EMC): -- United States / Canada:
-- Europe:
Safety Compliance: -- United States / Canada:
-- Europe:
-- Germany:
|
| Power Description | |
| Number of Power Supplies Installed | 4 |
| Maximum Power Supply Wattage | 1.62 kW |
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Number of PCI Express x16 Slots | 1 |
| Total Number of Expansion Slots | 1 |
| Memory | |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-1600/PC3-12800 |
| Total Number of Memory Slots | 16 |
| Controllers | |
| RAID Levels | 0, 1 |
| Controller Type | Serial Attached SCSI (SAS) |
| Serial ATA/300 | |
| RAID Supported | Yes |
| Processor | |
| Processor Supported | Xeon |
| Processor Socket | Socket R LGA-2011 |
| 64-bit Processing | Yes |
| QuickPath Interconnect | 8 GT/s |
| Number of Processors Supported | 2 |
| QuickPath Interconnect Supported | Yes |
| General Information | |
| Product Type | Server Barebone System |
| Manufacturer Part Number | SBI-7127R-SH |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | SBI-7127R-SH |
| Product Name | Processor Blade SBI-7127R-SH (Black) |
| Product Line | SuperBlade |
| Brand Name | Supermicro |
| Physical Characteristics | |
| Weight (Approximate) | 8.60 lb (3900.89 g) |
| Form Factor | Blade |
| Rack Height | 42U |
| Height | 11.32" (287.53 mm) |
| Width | 1.67" (42.42 mm) |
| Depth | 18.90" (480.06 mm) |
| Product Color | Black |
| Color Family | Black |
